Page 1: Table Of Contents
7 DEALER MANUAL FOR DP E161.CAN CONTENT 7.1 Important Notice 7.7 Normal Operation 7.2 Introduction of Display 7.7.1 Switching the System ON/OFF 7.3 Product Description 7.7.2 Selection of Support Levels 7.3.1 Specifications 7.7.3 Headlights / backlighting 7.3.2 Functional Overview 7.7.4 Walk Assistance 7.4 Display Installation... -
Page 2: Important Notice
• Do not clean the display with a steam jet, high-pressure cleaner or water hose. 7.2 INTRODUCTION OF DISPLAY • Model: DP E161.CAN BUS • The label marking is as follows: • The housing material is PC+ABS and acrylic, as following: Note: Please keep the QR code label attached to the display cable. -
Page 3: Product Description
7.3 PRODUCT DESCRIPTION 7.3.2 Functional Overview 7.3.1 Specifications • Battery capacity indicator • Operating temperature: -20℃~45℃ • Indication of support level • Storage temperature: -20℃~50℃ • Walk assistance • Waterproof: IP65 • Automatic sensors explanation of the light- • Storage room Humidity: 30%-70% RH ing system •... -
Page 4: Display
7.5 DISPLAY Battery capacity indicator Speed indicator Support level indicator Walk assistance Indicator for lighting system Bluetooth indicator 7.6 KEY DEFINITION E161 Display has three buttons: System On/Off , Up and Down System On/Off Down BF-DM-C-DP E161-EN November 2019... -
Page 5: Normal Operation
7.7 NORMAL OPERATION 7.7.1 Switching the System ON/OFF 7.7.3 Headlights / backlighting Press and hold (>2S) on the display to Hold the (>2S) button to activate the turn on the system. headlight and taillights. Press and hold (>2S) again to turn off Hold the (>2S) button again to turn off the system. -
Page 6: Battery Capacity Indication
When the mobile phone is connected to the display by Bluetooth, the Bluetooth symbol will be displayed, and the disconnected symbol will disappear automatically. This display can be connected to the Bafang Go APP through Bluetooth. More information can be viewed on the APP, such as the information of battery, remaining capacity, single-trip distance. -
Page 7: Error Code Definition
7.8 ERROR CODE DEFINITION DP E161.CAN display can provide warning for failures. The error code flickers when an error is detected. Note: please read carefully the description of the error code. When the error code appears, please first restart the system. If the problem is not eliminated, please contact your dealer or technical personnel. - Page 8 Error Declaration Troubleshooting 1. Check all connectors from the battery are correctly connected to the motor. Error with the temperature sensor inside of the battery 2. If the problem still occurs, please change the Battery. 1. Allow the pedelec to cool down and restart the The protection temperature system.
- Page 9 Error Declaration Troubleshooting 1. Check that all connections are connected correctly. 2. Please connect the pedelec to the BESST system to see if speed signal can be read by the BESST tool. Speed signal of the torque 3. Change the Display to see if the problem is solved. sensor has an error 4.
- Page 10 Error Declaration Troubleshooting Using the BESST tool update the controller to see if WDT circuit is faulty this resolves the problem. If not, please change the controller or contact your supplier. Total voltage from the battery is Please change the battery. too high Total voltage from the battery is Please Charge the battery.
