Summary of Contents for BAFANG DP C240.CAN

  • Page 1: Table Of Contents

    CONTENT DP C240.CAN CONTENT Content Button definition Introduction Normal operation Overview drawing Functions setting Specifications BESST connection Functions overview Error code definition Normal indication area Installation DISPLAY MANUAL DP C240.CAN...
  • Page 2: Introduction

    A. Up line (as below) PD2526051205 - Parameter code DP C240.C 1.0 The last two lines: ① DP C240.C: BAFANG display mode DP C240.C 1.0 / 607K1Q7280001 - SN ② 1.0: Hardware version number B. Down line (as below) 607K1Q7280001 ①...
  • Page 3: Overview Drawing

    OVERVIEW DRAWING OVERVIEW DRAWING DISPLAY MANUAL DP C240.CAN...
  • Page 4: Specifications

    • Rated voltage: 36V/43V/48V DC • Rated current: 10mA • Storage temperature: -30℃~70℃ • Maximum operating current: 30mA • IP level: IP65 • Power-off leakage current: <1uA • Storage ambient humidity: 30%-70% • Operating current supplied to controller: 50mA DISPLAY MANUAL DP C240.CAN...
  • Page 5: Functions Overview

    • 5 levels of backlight brightness setting. • USB charging port: ≤5V, ≤1A. • Indication for power assistance level with 6 levels:0/1/2/3/4/5. • Dual Bluetooth integrated. • Indication for trip: To indicate single-trip dis- tance, total distance and remaining distance. DISPLAY MANUAL DP C240.CAN...
  • Page 6: Normal Indication Area

    Battery capacity indication: color Arabic number; No chosen level indica- Indicate the current remaining capacity. tion means level 0, no power assistance, means push assistance mode. Real-time speed indication: To indicate the real-time speed. DISPLAY MANUAL DP C240.CAN...
  • Page 7: Button Definition

    Press and hold” ON/OFF” button, then display is working and offering power to controller; On the contrary, press and hold this button,then display is off and the cur- rent consumption is less than 1uA . Welcome interface DISPLAY MANUAL DP C240.CAN...
  • Page 8 On the contrary, press and hold ”+” again to turn off the display backlight and the headlight (If the display is turned on in a dark environment.the display backlight/ headlight are turned off manually, they also need to be turned on manually afterwards). Interface of headlight and backlight DISPLAY MANUAL DP C240.CAN...
  • Page 9 USB charging indication the current assistance level. • Bluetooth connection: ① This display has Bluetooth module inte- grated and connectable to BAFANG’s own smart phone application “BAFANG GO”. In addition, the SDK is open for customer to Push assistance function develop APP individually.
  • Page 10: Functions Setting

    Press and hold “+” & “-” button synchronously to enter into Display Setting interface, and briefly press “+” or “-” to switch to from “Setting” to “EXIT“ and then briefly press “ON/OFF” button to confirm the operation. Switch interface Settable menus Viewable data DISPLAY MANUAL DP C240.CAN...
  • Page 11 ”ON/OFF” to select and then briefly press ”ON/OFF” to select am among“0”/ “1”/“2”/“3”/“4”/“5” five levels, ong“100%”/“75%”/“50%”/“30%”/“10%” then briefly press ”ON/OFF” to confirm five levels, then briefly press ”ON/OFF” to selection and save the setting and exit back DISPLAY MANUAL DP C240.CAN...
  • Page 12 After entering into “Information” menu, then briefly press “+” or “-” to go to ” Speed Limit”, and then briefly press ”ON/OFF” to review the speed limit default, hen briefly press ”ON/OFF” to exit back to the “Speed DISPLAY MANUAL DP C240.CAN...
  • Page 13 ”ON/OFF” to exit back to the “Battery Info.”. Press and hold “+” and “-” synchronously to save and exit back to the main interface, or you can also select “BACK” → “EXIT” to exit back to the main interface. DISPLAY MANUAL DP C240.CAN...
  • Page 14: Besst Connection

    • If the display show ”Write OK”, it means it • Firmware update. is successful for BESST BOX to write basic information into the display. The informa- tion includes customer’s number, wheel size, speed limit. DISPLAY MANUAL DP C240.CAN...
  • Page 15: Error Code Definition

    ERROR CODE DEFINTION ERROR CODE DEFINITION DP C240.CAN display can show e-bike faults. When a fault is detected, the icon will be displayed. One of the following error codes will be displayed. Error Explanation Troubleshooting Brakes enabled Check whether a brake cable is stuck.
  • Page 16: Installation

    A. Display unit B. Support bracket C. M3 screw • Pull out the clamp of the support bracket and put it around the handlebar and then fix it with M3 screw.(≤1N.m) D. Clamp E. Hex socket screw M3*30 DISPLAY MANUAL DP C240.CAN...
