Summary of Contents for BAFANG DP E170.CAN
-
Page 1: Table Of Contents
7 DEALER MANUAL FOR DP E170.CAN CONTENT 7.1 Important Notice 7.6 Key Definition 7.2 Introduction of Display 7.7 Normal Operation 7.3 Product Description 7.7.1 Switching the System ON/OFF 7.3.1 Specifications 7.7.2 Selection of Support Levels 7.3.2 Functional Overview 7.7.3 Headlights / backlighting 7.4 Display Installation... -
Page 2: Important Notice
• Do not clean the display with a steam jet, high-pressure cleaner or water hose. 7.2 INTRODUCTION OF DISPLAY • Model: DP E170.CAN • The label marking is as follow: Note: Please keep the QR code label attached to the display cable. The information from the Label is used for a later possible software update. -
Page 3: Product Description
7.3 PRODUCT DESCRIPTION 7.3.2 Functional Overview 7.3.1 Specifications • Battery capacity indicator • Operating temperature: -20℃~45℃ • Switch on and off • Storage temperature: -20℃~60℃ • Indication and selection of support level • Waterproof: IPX5 • Control of lighting system •... -
Page 4: Display Information
The RGB light flashes at a frequency of 1Hz. 7.6 KEY DEFINITION DP E170.CAN has a single button, which achieves to power on and off the machine, select the support levels, and switch on and off the headlight. BF-DM-C-DP E170-EN November 2019... -
Page 5: Normal Operation
7.7 NORMAL OPERATION 7.7.1 Switching the System ON/OFF 7.7.3 Headlights / backlighting Press and hold (>2S) on the display to ON: Double click when the light is off, turn on the system. and the controller will turn on the lights. Press and hold (>2S) again to turn off OFF: Double click... -
Page 6: Error Code Definition
7.8 ERROR CODE DEFINITION The display can show the errors of a pedelec. When the fault is detected, the RGB lights will flash at a frequency of 1 Hz. The flashing blue light indicates the tens digit of the error code, while the flashing cyan light indicates the unit digit. - Page 7 Error Declaration Troubleshooting 1. Check all connectors from the battery are correctly connected to the motor. Error with the temperature sensor inside of the battery 2. If the problem still occurs, please change the Battery. 1. Allow the pedelec to cool down and restart the The protection temperature system.
- Page 8 Error Declaration Troubleshooting 1. Check that all connections are connected correctly. 2. Please connect the pedelec to the BESST system to see if speed signal can be read by the BESST tool. Speed signal of the torque 3. Change the Display to see if the problem is solved. sensor has an error 4.
- Page 9 Error Declaration Troubleshooting Using the BESST tool update the controller to see if Controller WDT circuit is faulty this resolves the problem. If not, please change the controller or contact your supplier. Using the BESST tool update the sensor to see if Sensor WDT circuit is faulty this resolves the problem.
