Installing The Air Filter Box Cover; Removing The Air Filter - KTM 150 XC-W 2018 Owner's Manual

12.21

Installing the air filter box cover

12.22

Removing the air filter

Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
–
Never start to use the vehicle without an air filter.
Warning
Environmental hazard Hazardous substances cause environmental damage.
–
Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with
the applicable regulations.
–
Insert the air filter box cover in area
area B .
V00346-12
Condition
The air filter box cover is secured.
–
Mount and tighten screw
Guideline
Screw, air filter box
cover
V00346-10
Preparatory work
–
Remove the air filter box cover. (
Main work
–
Detach retaining tab
port.
–
Remove air filter from air filter support.
V00345-10
12 SERVICE WORK ON THE CHASSIS
A and clip it into
1 .
EJOT PT ®
K60x20-Z
p. 68)
1
. Remove air filter with air filter sup-
3 Nm (2.2 lbf ft)
69
