Installation
Connection diagram
• Electrical connections must be as shown in the diagram below.
• Use cable bushes.
• Make sure that cables cannot chafe.
• Observe relay current rating.
• In all cases use contactors for pump and compressor.
• Do not feed digital inputs with external voltage! Use potential-free switches.
Note: see wiring diagram in Appendix 1
