CAREL Easy Milk Chiller

Technical Specifications

Wiring Diagram

38
Power Supply (*) 230 Vac +10/-15% 50/60 Hz; 115 Vac +10/-15% 50/60 Hz
12 Vac +10/15% 50/60 Hz class 2; 12 Vdc +10/-20% class 2;
Rated Power 3.5 VA
Inputs (*) NTC or PTC probes 1 or 3 inputs
Digital input as alternative to third probe
Relay outputs (*) 2 HP relay UL: 12 A Res. 12 FLA 72 LRA - 240 Vac (***)
16 A relay UL: 12 A Res. 5 FLA 30 LRA - 240 Vac C300,
8 A relay
Type of Probe (*) Std CAREL NTC 10K Ω at 25 °C, Std CAREL PTC 985 Ω at 25 °C
Connections (*) Screw terminals for cables with cross-sect. from 0.5 mm
Plug-in terminals for screw blocks or with crimped contact (cable cross-sect.
up to 2.5 mm
Assembly (*) Terminal: using screws from the front panel or with rear brackets.
Interface: wall mounting, 4 screws, spacing 101 x 151mm
Display 3 digit LED display with sign (-199 to 999) and decimal point; six status LEDs
Operating conditions
Storage conditions
Range of measurement
Front panel index of protection
Case
Classification according to protection
against electric shock
Environmental pollution
PTI of the insulating material
Period of stress across the insulating parts
Category of resistance to heat and fire
Immunity against voltage surges
Type of action and disconnection
No. of relay automatic operating cycles (*)
Software class and structure
Cleaning the instrument
Cable max. length
EN60730-1: 10(10) A 250 Vac (**)
EN60730-1: 12(2) A NO/NC, 10(4) A up to 60 °C NO,
2(2) A CO - 250 Vac
UL: 8 A Res. 2 FLA 12 LRA - 240 Vac C300,
EN60730-1: 8(4) A NO, 6(4) A NC, 2(2) A CO - 250 Vac
). Rated maximum current per terminal 12A.
2
-10T50 °C - humidity ,<90% rH non-condensing
-20T70 °C - humidity ,<90% rH non-condensing
-50T90 °C (-58T194 °F) - resolution 0.1 °C/ °F
Panel installation with IP65 type 1 gasket
Plastic terminal, 81 x 36 x 65 mm
Class II when suitably integrated
Normal
250 V
Long
Category D (UL94-VO)
Category 1
1C relay contacts
EN60730-1:
UL:
Class A
Only use neutral detergents and water.
Serial: 1 km
Probes: 30 m
Relay: 10 m
Code
PJS1Y0P000
PJS1Y0V000
2 to 1.5 mm 2 .
100,000 operations
30,00 operations (250 Vac)
Description
Easy milk chiller 2 relays
16 A compressor relay
8 A stirrer relay
Easy milk chiller 3 relays
16 A compressor relay
8 A stirrer relay
8 A AUX relay
