CAREL Easy Milk Chiller
Default Parameters CAREL (for back-up cooling)
TABLE OF PARAMETERS
PARAMETER
PS PASSWORD
/ PROBE PARAMETERS
/2 Measurement stability
/4 Select probe/input displayed (1= probe 1, 2= probe 2, 3= probe 3)
/5 Select °C / °F ( 0 = °C; 1 = °F)
/6 Disable decimal point
/C1 Probe 1 calibration
/C2 Probe 2 calibration
/C3 Probe 3 calibration
r CONTROL PARAMETERS
St1 Set point 1
rd1 Control differential 1 (referred to setpoint 1)
St2 Set point 2
rd2 Control differential 2 (referred to setpoint 2)
r1L Minimum user set point allowed (setpoint 1)
r1H Maximum user set point allowed (setpoint 1)
r2L Minimum user set point allowed (setpoint 2)
r2H Maximum user set point allowed (setpoint 2)
r3 Operating mode 1= direct; 2= reverse
r4 Automatic night-time set point variation
c COMPRESSOR PARAMETERS
c0 Compressor and fan start delay after start-up
c1 Minimum time between successive compressor starts
c2 Minimum compressor OFF time
c3 Minimum compressor ON time
c4 Compressor safety (duty setting)
cc Continuous cycle duration
c6 Alarm bypass time after continuous cycle
A ALARM PARAMETERS
A0 Alarm and fan differential
AL Low temperature alarm threshold/deviation (AL= 0 alarm disabled)
AH High temperature alarm threshold/deviation (AH= 0 alarm disabled) F
Ad Low and high temperature alarm delay
A4 Digital input configuration
A7 External alarm detection delay
Ac High condenser temperature alarm
AE High condenser temperature alarm differential
Acd High condenser temperature alarm delay
P STIRRER PARAMETERS
P1 Stirrer actuator duration after chill cycle
P2 Interval between two activations of the stirrer
P3 Manual short stirring cycle duration
P4 Manual long stirring cycle duration
P5 Stirrer in automatic mode
