Hans Grohe Tango C 04270 5 Series Installation/User Instructions/Warranty page 5

Tango C
04270xxx
3⅛"
(79 mm)
2¼"
(57 mm)
1⅛" (29 mm)
½ NPT
5" (127 mm)
2½"
(64 mm)
8" (200 mm)
2¼"
(57 mm)
1¼"
(32 mm)
1¼" O.D.
(32 mm)
Tools Required / Outiles Utiles /
Herramientas Útiles
9 mm
16 mm
17 mm
5
