Summary of Contents for Hans Grohe Swing C 04053 0 Series
- Page 1 Installation Instructions / Warranty Swing C Swing C 04053xx0 04054xx0 Swing C Solaris E 04055xx0 04056xx0...
-
Page 2: Technical Information
Vertical Spray Bidet Mixer Swing C Solaris E 04053xx0 Cross handles 04056xx0 04054xx0 Scroll handles 04055xx0 Lever handles 04053xx0 04054xx0 04055xx0 04056xx0 Technical Information Installation Considerations Recommended operating pressure 45 - 80 psi • For best results, Hansgrohe recom- Recommended hot water temp. 120°- 140°... - Page 3 Install the transfer valve Install the y-connector and seal on the bottom of the transfer valve. Screw the connecting hoses to the y-connector. Screw the elbow connector to the outlet port on the side of the transfer valve. The arrow on the elbow connector indicates the direction of the water flow.
- Page 4 Install the pop-up guide assembly Remove the nut, metal washer, and sealing washer from the pop-up guide assembly. Position the pop-up guide and sealing washer on the proper hole on the bidet. Install the metal washer and nut. Overtightening the nut may result in damage to the bidet.
- Page 5 Install the valves – all other models Remove the mounting plates and stop rings from the valves. Push the valve up through the hole. Slide the stop ring onto the valve. Install the mounting plate. The stop ring will stop it at the proper height. Rest the mounting plate on the mounting surface.
- Page 6 Install the handles – all other models Install the deco rings on the handles. Hold the lever or cross part of the handle in the desired “off” position with one hand. With the other hand, turn the bell part of the handle clockwise, so that it threads down over the valve stem.
-
Page 7: Installation / Installation / Instalación
Installation / Installation / Instalación... - Page 8 User Instructions cold Note: Water will continue to flow from the rim wash while the vertical spray runs. This is normal and does not indi- cate a product defect.
-
Page 9: Replacement Parts
Replacement Parts 1 valve set 88503000 2 mounting kit 88511000 3 hot cartridge 94009000 4 cold cartridge 94008000 5 transfer valve 88632000 6 sleeve 88635xx0 7 transfer valve handle 88636xx0 8 hot/cold connection hose 88631000 9 spray hose 88630000 10 pull rod 88634xxX 11 aerator 88633xx0... - Page 10 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
-
Page 11: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. - Page 12 EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
