AD-FMCMOTCON1-EBZ Linux on Zynq Quick

Start Guide

This guide provides some quick instructions (still takes awhile to download, and set things up) on how

to setup the AD-FMCMOTCON1-EBZ on either:

ZED

Board, Rev C or later

Requirements

You need a Host PC (Windows or Linux).

You need a SD card writer connected to above PC (Supported USB SD readers/writers are OK).

USB keyboard/mouse for the Zynq Device

HDMI Display (monitor or TV)

Create SD Image for Zynq Boards

On the boot partition on the SD card, the boot.bin and devicetree.dtb specific to the motor control

project must be copied. They can be downloaded from:

Boot files for ZED board

Instruction regarding the hardware connection can be found at:

Hardware connection user guide ZED board
