Configuration verification
On the AP shown in Figure
shown in Figure 6-5, where you can check that the workgroup bridge is online.
Figure 6-5 Check that the workgroup bridge is online
You can see that the client with MAC address 0014-6c8a-43ff and the workgroup bridge with MAC
address 000f-e2333-5510 have been successfully associated with the AP.
The wired devices on the right (such as printers and PCs) can access the wireless network through
the workgroup bridge.
Configuration guidelines
As shown in Figure
client connecting to radio 2 can access the AP through the workgroup bridge.
Figure 6-6 Network diagram for a workgroup bridge using two radio interfaces at the same time
When satisfied with the configuration
Access Point restarts.
6-1, select Summary > Client from the navigation tree to enter the page
6-6, if the workgroup bridge uses two radio interfaces at the same time, the
Save Configuration to File
6-3
to ensure it is not lost when the
