3Com AP9152 Quick Configuration Manual page 32

Figure 3-40 Configure the AAA accounting method for the ISP domai
Perform the following configuration, as shown in
Select the domain name system.
Select the Accounting Optional checkbox and then select Enable.
Select the Default Accounting checkbox and then select RADIUS as the accounting mode.
Select system from the Name drop-down list to use it as the accounting scheme.
Click Apply. A configuration progress dialog box appears.
After the configuration process is complete, click Close.
4) Configure wireless service
# Create a wireless service.
Select Wireless Service > Access Service from the navigation tree, and click New to enter the page
for creating a wireless service, as shown in
Figure 3-41 Create a wireless service
Set the service name as dot1x.
Select the wireless service type crypto.
Click Apply.
5) Configure 802.1X authentication
After you create a wireless service, you will enter the wireless service configuration page. Then you can
configure 802.1X authentication on the Security Setup area, as shown in
Figure 3-40.
Figure 3-41:
3-22
n
Figure 3-42:
