Figure 4-3 WDS setup pag
Select the Pass Phrase check box, and input 12345678 in the Preshared Key input box.
Do not set the neighbor MAC address, indicating that the AP can establish a WDS link with any
other AP.
Click Apply.
3)
Configure the same working channel.
Select Radio > Radio from the navigation tree, select the radio unit to be configured in the list, and click
the corresponding
icon to enter the Radio page, as shown in
Figure 4-4 Configure the working channel
Select the channel to be used from the Channel drop-down list.
e
4-2
Figure
4-4.
