Select Radio > Radio from the navigation tree to enter the Radio page. Make sure that 802.11g is
enabled.
8) Configure the RADIUS server (iMC)
The following takes the iMC (iMC PLAT 3.20-R2602 and iMC UAM 3.60-E6102) as an example to
illustrate the basic configuration of the RADIUS server.
# Add an access device.
Log in to the iMC management platform. Select the Service tab, and then select Access Service >
Access Device from the navigation tree to enter the access device configuration page. Click Add on
the page to enter the configuration page as shown in
Input expert as the Shared Key.
Add ports 1812, and 1813 for Authentication Port and Accounting Port respectively.
Select LAN Access Service for Service Type.
Select H3C for Access Device Type.
Select or manually add the access device (the AP) with the IP address 10.18.1.1.
Figure 3-44 Add access device
# Add service.
Select the Service tab, and then select Access Service > Service Configuration from the navigation
tree to enter the add service page. Then click Add on the page to enter the following configuration page.
Set the service name as dot1x.
Set the Certificate Type to EAP-PEAP AuthN and the Certificate Sub Type to MS-CHAPV2
AuthN.
Figure 3-44:
