3Com AP9152 Quick Configuration Manual page 29

In the Network > VLAN page, create a VLAN on the fat AP, and in the Device > Interface
Management page, configure the VLAN interface.
2) Configure a RADIUS scheme
# Configure the RADIUS authentication server.
From the navigation tree, select Authentication > RADIUS. The RADIUS server configuration page
appears.
Figure 3-35 Configure the RADIUS authentication serve
Perform the following configuration, as shown in
Select Authentication Server as the server type.
Enter 10.18.1.88 as the IP address of the primary authentication server
Enter 1812 as the UDP port of the primary authentication server.
Select active as the primary server status.
Click Apply.
# Configure the RADIUS accounting server.
Figure 3-36 Configure the RADIUS accounting server
Perform the following configuration, as shown in
r
Figure 3-35.
Figure 3-36.
3-19
