5.5 Process monitoring screen

210.0 – working temperature set value. Press to change the value.
203.5 PV – current temperature in the chamber.
27.50 – set value for basic turbine speed. Press to change the value.
27.50 PV – current speed of the turbine.
batch counter 12 – batch counter (reset every time the machine is turned off).
15.6 – countdown timer for the stage of the operating cycle that takes place at the mo-
ment. Only shown when machine is in popping mode.
corn auger timer – the name of the stage that takes place at the moment (only when the
machine is in popping mode), including:
• corn auger timer – duration of corn feeding auger operation, in sec.
• popping timer – duration of popping stage, in sec.
• purge chamber timer – duration of purge stage, in sec.
When machine is not in popping mode, the following messages appear here:
• wait... heating – indicates that the machine is in heating mode.
• paused machine – indicates that the machine is in pause mode.
• clogging – indicates that the chamber is clogged.
T
– press to move to the temperature graph screen.
– press to return to the previous screen.
Figure 13: Process monitoring screen
