- Page 1 OPERATING MANUAL ROBOMIX MINI CAUTION: READ THE INSTRUCTIONS BEFORE USING THE MACHINE! PDF version of this manual is available on www.robolabs.pro...
-
Page 2: Table Of Contents
tm3971 Jan-20 Table of contents Safety requirements ................... 3 1. Overview ......................4 1.1. Purpose ....................4 1.2. Technical specifications ................4 1.3. Delivery set ..................... 4 1.4. Power requirements ................4 1.6. Ambient conditions .................. 5 1.7. Getting started ..................5 2. -
Page 3: Safety Requirements
tm3971 Jan-20 Safety requirements DO NOT WASH MACHINE WITH WATER! ONLY INSTRUCTED PERSONNEL ARE ALLOWED TO OPERATE THE MACHINE! DO NOT PROCESS OTHER PRODUCTS THAN POPCORN! DO NOT LEAVE RUNNING MACHINE UNATTENDED! ALL SWIVEL CASTERS MUST BE LOCKED WHILE IN OPERATION! DO NOT TURN THE MOTOR ON WITH OPEN CONTAINER! BEWARE MOVING PARTS! -
Page 4: Overview
1. Overview 1.1. Purpose RoboMix Mini coater is used for making popcorn coated with dry or liquid seasoning mixes of any kind: oil, cheese, tomato, salt, pepper, sugar powder etc. Both varieties of popcorn, Butterfly or Mushroom can be processed in the machine. -
Page 5: Ambient Conditions
tm3971 Jan-20 and call for qualified electrician! Equipotential bonding wire (up to 10 sq.mm) shall be connected to screw terminal marked with IEC 5021 sign. It is necessary to check electric wires and ground connection of the machine periodically. In case of faults found, an electrician must be called. It is allowed to turn the machine on only after all the issues are resolved. -
Page 6: Operation Mode
tm3971 Jan-20 Fig. 1 Main components 2.2. Operation mode Prepare popped popcorn, and seasoning mixture. It is recommended to use a mix of liquid oil and dry seasoning powder. The main purpose of oil is to provide proper binding of popcorn and seasoning. Fill the container with popped popcorn not more than 2/3 of its volume. -
Page 7: Technical Maintenance
tm3971 Jan-20 3. Technical maintenance The aim of technical maintenance is to keep the equipment in order during whole lifetime; and also to fulfill food safety requirements. Do not use abrasive materials to avoid scratches! Do not use steel or iron tools; it can cause stainless steel corrosion! Do not wash electric parts and compartments of the machine with water! Use a slightly dampen, soft cloth to clean the surfaces, wipe dry immediately... -
Page 8: Acceptance Certificate
tm3971 Jan-20 5. Acceptance certificate ACCEPTANCE CERTIFICATE __________________ № ________________________ Product Name Serial Number The equipment is made with accordance to mandatory requirements of the state standards, actual technical documentation, and approved for use. QC Engineer Stamp Here _________________ _________________ Signature Full Name _________________... -
Page 9: Warranty Obligations
Due to constant improvement of the equipment, technical specifications are subject to change without prior notice! 7. Manufacturer details NPO Tvertorgmash LLC 11 Industrial Street, Tver, 170000 Russia Technical support: Email: support@robolabs.pro Phone: +7 495 956 4000... -
Page 10: Annex A Wiring Diagram
tm3971 Jan-20 Annex A Wiring diagram SIGN ARTICLE# PART SPEC 11792 Capacitor CВВ61 1uF 450V AC 3811 Motor YN70-15/70JB36G10 Linix 3730 Rocker switch with backlight B4 MASK T120/55 3/4HP... -
Page 11: Annex B. Parts List
tm3971 Jan-20 Annex B. Parts list ITEM# ARTICLE# PART MODEL 1373 Locking swivel caster 75 mm 3730 Rocker switch with backlight B4 MASK T120/55 3/4HP 1094 Power plug 16А, 250В 20741 Power cable 4 m КГН 3х1,5 sq.mm 3931 Cable gland 11792 Capacitor CВВ61 1uF 450V AC...
