Summary of Contents for RoboLabs ROBOJETFLOSS ACB-09-120

  • Page 2 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 OPERATION MANUAL COTTON CANDY MACHINES ROBOJETFLOSS (ACB-09-120) ROBOJETFLOSS PRO (ACB-09-120-PRO) ROBOJETFLOSS RENT (ACB-09-120-R) 2018...

  • Page 3: Safety Requirements

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 SAFETY REQUIREMENTS Read the ENTIRE MANUAL before operating. Only allow TRAINED PERSONNEL to operate the Robo JetFloss. 1. DO NOT TURN ON until transport fastening nuts are fully RAISED. 2. DO NOT OVERFILL spinning head with flossugar. 3.

  • Page 4: Overview And Operation

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 1. OVERVIEW AND OPERATION 1.1. DESIGNATION ACB-09-120 is intended to produce cotton candy using sugar with or without flossine. Due to the patented design, the equipment allows operation under high ambient temperature and relative humidity. Candy floss leaves the machine vertically, producing servings up to 6 feet in diameter.

  • Page 5: Delivery Set

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 1.3. DELIVERY SET Delivery set of ACB-09-120 includes the following: Cotton candy machine 1 pc Plastic/aluminum floss pan 1 pc ‘No-Snow’ tool 1 pc Silicone sealing collar 1 pc Silicone adjustment ring 2 pcs Power supply cord 1 pc Operation manual...
  • Page 7 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 The front panel has the following controls: Switch (11) turns on the electric motor which rotates the spinning head; Switch (12) turns on the heating element; Adjustment Knob (13) regulates power to the heating element and thus controls its temperature;...

  • Page 8: Intended Use

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 2. INTENDED USE 2.1. PROTECTORS AND LOCKUPS Four nuts secure the spring-loaded chassis during transportation to prevent damage to the motor. They are located on the threaded support studs at each corner of the deck. Rubber legs and a spring suspension supports the chassis in order to minimize vibration and allow the spinning floss head to balance itself at high speed.
  • Page 12 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 ‘Cold start’ Procedure When the Robo JetFloss has been off for more than 15 minutes, it will take at least 60 seconds before the heating coil has warmed enough for the production of cotton candy to begin. If the machine has only been off for a brief time, such as to add more flossugar, this time will be reduced substantially.
  • Page 13 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 the flossugar. Doing so could result in overheating the flossugar and the the cotton candy would then be produced in a narrow rope that is difficult to capture. In an extreme scenario, the floss would be burnt and ejected as irregular flakes and sugar dust that would create a mess covering everything nearby in the immediate area.
  • Page 14 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 At the very beginning of operation. During the end of production. When there there is not enough flossugar remaining. If the coil and sidewall are overheated. In both the beginning and ending of operation, snow is produced as the heating element crosses the temperature threshold at which it can evenly and uniformly melt the flossugar in the bowl into quality cotton candy floss.
  • Page 17 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 stick, you will find that you can modify the shape of the snake. Once you have the hang of it, you will be able to step away from the machine, as far as 10' to 15' (depending on conditions) and the snake will follow you if you continue the proper winding rate.
  • Page 18 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 If you are shutting down for longer than one day, then you should perform a complete cleaning of the spinning head as described in the Technical Maintenance section below. Do not leave unused flossugar in the spinning head for more than a day or two as it can harden/caramelize and effect the balance of the head during future sessions, which could ultimately result in failure of the machine.

  • Page 19: Technical Maintenance

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 3. TECHNICAL MAINTENANCE 3.1. GENERAL INSTRUCTIONS ATTENTION! THIS PART OF OPERATION MANUAL IS INTENDED ONLY FOR TRAINED PERSONNEL EXPERIENCED WITH ELECTRICAL EQUIPMENT. The purpose of technical maintenance is extend the working life of the machine while fulfilling all safety requirements.
  • Page 21 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 handle in order to loosen the parts. The sidewall is made of high-grade stainless steel. Nevertheless, the part might be damaged by excessive tightening the screws, by throwing, or by heavy impact. 4. Remove central wing nut (21), steel washer (20), plastic holding washer (19).
  • Page 23 COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 3.4. STORAGE If the unit is not used for a prolonged period of time, then the routine maintenance must be performed before it is placed back into service.

  • Page 24: Troubleshooting

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 3.5. TROUBLESHOOTING DISCONNECT THE POWER SUPPLY BEFORE DIAGNOSTICS AND REPAIR. EMI FILTER MUST BE DISCHARGED BY CLOSING ALL THE PINS IN THE PLUG! FAILURE POSSIBLE CAUSE REMEDY Machine doesn’t turn No power at the wall Use a tester to check the voltage on all on when power switch socket.

  • Page 25: Transportation And Storage

    COTTON CANDY MACHINE ACB-09-120 rev 11-May-18 4. TRANSPORTATION AND STORAGE The equipment may be transported by any kind of covered vehicle, in accordance with local regulations. Ambient temperature during the transportation and storage must be between -13° F and +131° F. 5.

  • Page 26: Warranty Obligations

    Due to constant improvement of the equipment, technical specifications are subject to change without prior notice! 7. MANUFACTURER DETAILS NPO Tvertorgmash LLC 11 Industrial Street, Tver, 170000 Russia Technical support is available: Email: support@robolabs.pro Phone: +7 495 956 4000...
