Testing Screen - RoboLabs VPM-RGM2 User Manual

5.2 Testing screen

Operation time 14.2 – Total operation time in hours.
LOW CORN – Corn bin sensor indicator. Yellow when tripped.
CLOGGING – Chamber optical sensor indicator. Yellow when tripped.
DEFAULT – Reset all settings to default (password required, see below).
– Turbine ON/OFF button. Press once to start. Press again to stop. Reading in the right
low corner adjacent to the sign is the turbine speed in Hz.
– Auger start button. Press once to start a cycle of feeding. Reading in the right low corner
adjacent to the sign is the auger cycle timer.
– Press to proceed to the settings screen.
– Press to enter password (2325) required to reset the settings.
– press to return to the previous screen.
Figure 8: Testing screen
14
