5.1 Initial screen

The initial screen (Fig. 6) appears first after machine turned on.
Figure 6: Initial screen
v1.1 – version of software.
154.2 PV – current temperature in the chamber.
– press to start popping process.
v 1.1
– press to enter the testing screen.
– press and hold 1 sec to turn the machine off.
If chamber temperature sensor or chamber optical sensor needs to be checked, the machine will
show the error messages, see Fig. 7.
Figure 7: Error messages
13
