Omcan VP-IT-0300 Instruction Manual page 15

Model VP-IT-0300
Item No. Description
AO021 Body for 47718
AO022 Base for 47718
AO023 Cover for 47718
AO024 Lower Vacuum Chamber for 47718
AO025 Upper Vacuum Chamber for 47718
41618 Sealing Bar Complete for 47718
72249 Top Bar for 47718
72246 Gasket for 47718
AO026 Vacuum Gauge for 47718
AO027 Start/Stop Switch for 47718
47718
Position Item No. Description
1 AO028 Seal Switch for 47718
2 AO029 Welding LED for 47718
3 AO030 Green LED for 47718
4 AO031 Vacuum Pump for 47718
5 AO032 Pump Base for 47718
6 AO033 Solenoid Valve for 47718
7 AO034 Electronic Board for 47718
8 AO035 Filter Socket with Fuse for 47718
9 AO036 "N" Series Hose Set for 47718
10 AO037 "NF" Series External Filter for 47718
Parts Breakdown
Position Item No.
11 AO038
13 AO039
14 AO040
15 AO041
16 AO042
17 AO043
18 AO044
19 AO045
20
20
15
Description Position
Green Wiring for 47718 21
Black Wiring for 47718 21
Cable/Plug for 47718 22
Hinges with Screws for 47718 23
Vacuum Socket for 47718 24
Screw Rivet for 47718 25
Cover Screws for 47718 26
Base Feet for 47718 27
