- Page 1 Foundation Trough Door Kit Installation Guide TI0036 - Foundation Trough Door Kit Installation – Rev 12.19.23...
-
Page 2: Tools And Supplies Required
TOOLS & SUPPLIES REQUIRED DRILL PHILLIPS HEAD DRIVER SQUARE HEAD DRIVER HEX HEAD DRIVER LEVEL TAPE MEASURE PHILLIPS SCREW DRIVER ALLEN/HEX KEY TI0036 - Foundation Trough Door Kit Installation Guide... - Page 3 MID BASE TOP PLATE TROUGH KIT MID BASE POWER COVER PHILLIPS HEAD COMBI DOWEL PHILLIPS HEAD CAM DOOR DOOR HINGE DOOR MOUNTING CLEAT WIRE JUMPER #10 X 1" PHILLIPS PAN HEAD ZIPBOLT SURFACE CONNECTOR TI0036 - Foundation Trough Door Kit Installation Guide...
-
Page 4: Base Assembly
(shown below). Level the table using the provided levelers located on the End and Mid Base Columns. Remove shipping cleats at this time. Note: Manually install Phillips Head Combi Dowels and Phillips Head Cams with a screwdriver. Do not use a drill. TI0036 - Foundation Trough Door Kit Installation Guide... - Page 5 Center all Door Mounting Cleats in the trough and attach using #10 x 1" Door Hinges. Phillips Pan Head screws. Note: This step is critical for Door alignment. Multi-piece Door Mounting Cleats must be tight to each other and equally centered in the trough. TI0036 - Foundation Trough Door Kit Installation Guide...
-
Page 6: Top Assembly
FIG 3.3A (TOP ATTACHMENT) FIG 3.3B (TOP ATTACHMENT) Confirm top assembly is centered and in its final location. Attach the top to the table base using #10 x 1" Phillips Pan Head screws. TI0036 - Foundation Trough Door Kit Installation Guide... - Page 7 If needed, open all Doors and use the hinge adjustments to adjust Confirm the table is still level. The assembly is now complete. the Door fit. Note: Install all Doors at this time, if not done so already (Fig 2.2–2.3). TI0036 - Foundation Trough Door Kit Installation Guide...
- Page 8 800.815.7251 enwork.com 12900 Christopher Drive Lowell, MI 49331 Specifications subject to change without notice.
