Enwork Wall Mounted Tapered Credenza Installation Instructions Manual

Wall mounted credenzas

Advertisement

Quick Links

Wall Mounted Tapered Credenza
Wall Mounted Credenzas
Installation Instructions
EI0007 – Rev A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wall Mounted Tapered Credenza and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enwork Wall Mounted Tapered Credenza

  • Page 1 Wall Mounted Tapered Credenza Wall Mounted Credenzas Installation Instructions EI0007 – Rev A...
  • Page 2 INSTALLATION GUIDE 1) Parts and Fasteners Included #10-1.25 Phillips Flat WML20xxAx LZCEET30 Head Screw WMLB20xxAx ***NOTE: Dealer/Installer must determine wall construction and provide appropriate wall anchors to secure LZCLEET brackets...
  • Page 3: Tools And Supplies Required

    INSTALLATION GUIDE 2) Tools and Supplies Required Drill Level Phillips Bit Tape Measure...
  • Page 4 INSTALLATION GUIDE 3) Assembly Overview Before Beginning Installation: - Number of people required for assembly: 2 - The architectural wall must be able to support 100 pounds of weight per linear foot of credenza. (i.e. – 6’ Credenza = 600 pounds of support) - Determine wall construction and use appropriate wall anchors to secure LZCLEET brackets to wall.
  • Page 5 Fig 3.2 3.2.1) Install LZCEET brackets to wall. For a 3.2.3) Locate and install the upper LZCLEET wall mounted tapered credenza with a top brackets to wall. (Refer to Credenza height of 31”, your bottom LZCLEET bracket spacing page for dimensions) bracket should measure 16.3”...
  • Page 6 INSTALLATION GUIDE Buffet Height Credenza Bracket Spacing 3) Assembly Overview Fig 3.3...
  • Page 7 INSTALLATION GUIDE Credenza Bracket Spacing Overview 3) Assembly Overview 60”W 72”W 84”W & 96”W...
  • Page 8 INSTALLATION GUIDE Cross-Section of Installation 3) Assembly Overview Credenza Credenza mounted bracket Drywall Stud Wall mounted bracket...
  • Page 9 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
