EXTERNAL COMPONENTS
Position
6
indicator
Dose regulator
12
8
Tamper
Portafilter holder
11
Coffee
15
collection tray
8
Hopper security screw
3
K09652H00 | PROC-CAL/002/03 USER MANUAL | V. 29/06/2023
Hopper
1
lid
Coffee bean
2
hopper
Hopper
4
shutter
Grind
7
regulator
14
Doser lid
Ground
10
coffee
deposit
Dosing lever
9
Switch
13
ON-OFF
K3
