11. MAINTENANCE
11.3.6 When reassembling the regulator, face
the regulating brake ( ) with the shoe of the
Parallel System and tighten until they link
(Fig. 13). Turn the regulator until the position
meets the previous one that you take a
note in the point 12.3.3 and keep going by
reversing the steps (Fig. 14).
Fig. 13 Fig. 14
11.4 REPLACING THE SILICONE
CURTAIN
Only for a K6 model: The silicon curtain
ensures regularity in the dose and reduces
static electricity. Located inside the coffee
spout, can be replaced once the regulator
has been removed from the grinder (Fig. 10).
Using a # 3 Allen key, the screw is loosened
and the curtain support is removed to gain
access to the silicone curtain, being able to
replace it with a new one or of a different
thickness according to the needs of each
coffee. (Fig. 15).
Fig. 15
