From that point, if your grinder is a K6 skip
until the point 11.3.5. if not, keep following
the next the steps:
11.3.3 Loosen the grinding regulator screws
using an Hex Allen screwdriver #3, according
to (Fig.3). Remove the regulator by pulling
up. (Fig.4).
Fig. 3
11.3.4 Turn the grinding regulator clockwise
until it is removed from its seat. Clean the
inside of the grinding cavity with a brush
or vacuum cleaner and remove any coffee
residue as well as the lubricant from the
threads of the upper burr holder and the
grinding cavity (Fig.5). and (Fig.6).
Fig. 5
Renew the food lubricant of the threads of
the upper cutter holder and of the grinding
cavity. Insert the upper cutter holder, turning
it counterclockwise until the upper and
lower cutter touch and cannot be turned any
further.
K09652H00 | PROC-CAL/002/03 USER MANUAL | V. 29/06/20023
11.3.5 Loosen the grinding regulator screws
using an Hex Allen screwdriver #3, according
to (Fig. 7). Before remove the regulator take
a look to the position in the scale and take a
note. (Fig. 8).
11.3.6 Loosen the regulation brake (
Fig. 4
it feels free from the Parallel (Fig. 9). Remove
the regulator by pulling up (Fig. 10).
11.3.7 Loosen the upper burs support screws
with a Hex Allen screwdriver #3, according to
(Fig. 11). Remove the upper holder by pulling
upwards to access the grinding cavity,
clean the interior with the help of a brush
or vacuum cleaner and remove any coffee
Fig. 6
residue from the grinding cavity (Fig. 12).
11.
MAINTENANCE
Fig. 7
Fig. 9
Fig. 11
Fig. 8
) until
Fig. 10
Fig. 12
17
