48
Series 90PLUS Operator's Guide
Connect the Parallel Cable
Back of
Printer
1. Turn off the printer and host system or personal computer.
2. Connect the 25-pin parallel interface cable to the connector located on the
back of the printer.
Refer to the Appendix for information on the parallel cable requirements.
3. Tighten the two mounting screws on each side of the cable connector.
25-pin Parallel
Interface Connector
