Select the Driver
CAUTION:
proper current for this luminaire by default. You must con-
figure the channel on the driver to 350 mA. Connecting the
luminaire to a channel that is configured for more than 350
mA will shorten the life of the luminaire LEDs and may void
the luminaire warranty.
This release of the Source Four Mini LED luminaire is compatible with the
R12 CC-150 output card or the W1 CC driver. Set the output channel for
the luminaire to 350 mA.
For more information about compatible products, see the resources below,
which are available for download at
trols/LED-Drivers/F-Drive/Documentation.aspx:
• F-Drive Series R12 Installation Manual
• F-Drive Series W1 Installation Manual
• F-Drive R12 and W1 Wiring Reference Guide
• F-Drive B-Box4 Installation Guide
The F-Drive System Design Tool is available at
nect.com/FDriveSysDesignTool.
RJ45 Pinout Information
Pin Description
1 - *
2,6 THRU 1**
3,7 THRU 2**
4,8 THRU 3**
5 + *
*Pins 1 and 5 receive power from the source or the previous luminaire in line.
**These pins pass through power to the next luminaires in line.
Pin Description
1,5 THRU 1
2,6 THRU 2
3,7 THRU 3
4,8 No Connection
