- Page 1 MANUAL ENGLISH Parcan 64 COB UV Ordercode: 80332 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Parcan 64 COB UV Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Overview .................................. -
Page 3: Warning
Your shipment includes: ● Showtec Parcan 64 COB UV with 1,5m Schuko power cable ● User manual Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ●... - Page 4 For replacement, use fuses of same type and rating only. The user is responsible for correct positioning and operating of the Parcan 64 COB UV. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device.
-
Page 5: Operating Determinations
Parcan 64 COB UV Operating Determinations ● This device is not designed for permanent operation. Regular operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light-output and the illuminated surface must be bigger than 0,5 meter. -
Page 6: Connection With The Mains
Parcan 64 COB UV The Parcan 64 COB UV can be placed on a flat stage floor or mounted to any kind of truss by a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power plug. -
Page 7: Return Procedure
Parcan 64 COB UV Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 8: Description Of The Device
Parcan 64 COB UV Description of the device Features The Showtec Parcan 64 COB UV is a blacklight effect with high output. • Light source: 100W UV COB • Wavelength: 400nm • Beam Angle: 90° • Max distance: 15m • Power consumption: max 110W •... -
Page 9: Installation
Parcan 64 COB UV Installation Remove all packing materials from the Parcan 64 COB UV. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 10: Product Specifications
The power supply settings do not • Disconnect fixture. Check settings match local AC voltage and and correct if necessary frequency Product Specifications Model: Showtec Parcan 64 COB UV Input voltage: 100-240V AC, 50/60Hz Power consumption: max 110W Light source: 100W UV COB Wavelength:... -
Page 11: Dimensions
Parcan 64 COB UV Dimensions Ordercode: 80332... - Page 12 ©2017 Showtec...
