A 2 B Interrupt ( Ds4) - Analog Devices EVAL-AD2437A1NZ Manual

LEDs
DS1
DS2
DS4
DS5
DS6
DS8
DS9
DS11
DS12 DS13
DS10
Figure 3-4: LED Locations
2
A B Interrupt ( DS4)
2
The A B interrupt LED is driven by the AD2437. The LED is turned on when the IRQ pin drives it high. Refer to
the TRM for further info on using interrupts.
EVAL-AD2437A1NZ Manual 3–13
