Jumpers
JP2
JP3
P9
JP1
Figure 3-3: Jumper Configurations
Boot ( P9)
The Boot jumper allows the ADAU1701 to perform a self boot, in which it loads its RAM and register settings from
an external EEPROM. When the jumper is installed no self boot operation is initiated. When the jumper is re-
moved a self boot operation is initiated the next time there is a rising edge on the RESET signal of the ADAU1701.
This jumper is installed by default.
Gain ( JP2)
Gain terminal sets the gain of the amplifier. Please set GAIN after setting MUTE low. A pop noise may occur if
GAIN is set while MUTE is high.
3–6
EVAL-AD2437B1NZ Manual
