LED PORT

DS3 SIO2

Port Connection Status ( DS4, DS8, DS9 and DS12)

When XLR cable is plugged in, the rings will illuminate indicating a successfull connection.

Mute status LED. when MUTE is driven high, the LED will be on, when driven low, the LED will be off.

24V power indication. This LED will turn on when 24V is present on the board. DS10 : +24.0V @3.0A
