Hardware Description
5
Appliance rail screws
6
Ear mount bracket screws
7
Round hole pins
Rack Mounting Tools
We recommend that you use a Phillips PH2 screwdriver with a magnetic head to hold and retrieve screws.
16000, 26000, and 28000 Security Appliances Installing the Telescopic Rails
Qty
Use
12
Attaches the appliance rails to the
appliance
4
Attaches the ear mounts to the appliance
or
4 ear mount screws for 16600HS and
28600HS
6
6 ear mount screws for 16000, 16200,
26000, and 28000
8
Attaches to the outer rack rails
Note - Needed for round hole racks only
16000, 26000, and 28000 Appliances Telescopic Rails | 8
