Summary of Contents for Quantum TC2201E
-
Page 2: Copyright Statements
Quantum Corporation is prohibited by law and constitutes a punishable violation of the law. TRADEMARK STATEMENT DLT, SDLT, DLTtape III, DLTtape IV and Super DLTtape I are all trademarks of Quantum Corporation. Other trademarks may be mentioned herein which belong to other companies. -
Page 3: Table Of Contents
Preface Chapter 1 Introduction External Features ... 1 Operation Indicators... 2 How the TC2201E Works... 3 Processing SCSI Information... 4 LAN-free Backup and Restore ... 6 TC2201E Features... 6 iSCSI Features ... 6 SCSI Bus Features... 7 Management Features ... 7 TC2201E Benefits... - Page 4 Setting Up Serial Port Communications ...23 Connecting the Power Cable ...24 Configuring the TC2201E...25 Configuring the TC2201E using the Visual Manager ...25 Configuring the TC2201D Using the Command Line Interface...27 Save Backup Version of Configuration ...28 Advanced Configuration Options ...29 iSCSI Configuration ...29...
- Page 5 Event Log Settings ... 78 > > Utilities Event Log ... 80 > > Utilities Clear Event Log... 81 > > Utilities SCSI Command Tracking ... 82 > Features... 84 > Report... 85 > Reboot ... 86 Quantum TC2201E User’s Guide Contents...
- Page 6 Parallel SCSI Buffered Tape Write Configuration Menu ...120 Device Mapping ...122 Trace and Event Settings Configuration...136 Real-Time Clock Configuration ...144 Save Configuration ...144 Restore Last Saved Configuration ...144 Reset and Save Configuration to Factory Defaults ...145 Quantum TC2201E User’s Guide...
- Page 7 Procedure B: Veritas NetBackup ... 163 Procedure C: Veritas Backup Exec ... 164 Procedure D: CA Brightstor ARCserve ... 165 Procedure E: Bakbone NetVault ... 166 Procedure F: HP Data Protector... 167 Procedure G: CommVault Galaxy... 169 Glossary Quantum TC2201E User’s Guide Contents...
- Page 8 Contents viii Quantum TC2201E User’s Guide...
- Page 9 Mounting at Back of the Rack... 17 Figure 13 Port locations... 18 Figure 14 WWN/MAC ID label ... 18 Figure 15 iSCSI ports ... 19 Figure 16 High Density SCSI Cables... 20 Figure 17 TC2201E SCSI connection ... 21 Quantum TC2201E User’s Guide Figures...
- Page 10 Figure 43 Figure 44 Figure 45 Figure 46 TC2201E Ethernet port ...22 TC2201E Serial Port ...23 TC2201E Power Switch and Connector...25 Visual Manager Home Page...35 TC2201E Image...35 Main Menu...36 System Page ...37 Serial port settings page...38 iSCSI Settings Page ...39 iSCSI Authentication Settings Page ...40...
- Page 11 Features Page ... 84 Figure 58 Report page ... 85 Figure 59 Reboot Page... 86 Figure 60 TC2201E LEDs ... 88 Figure 61 Clear all Entries from Current Map... 129 Figure 62 Registry Editor ... 163 Figure 63 Veritas Backup Exec... 165 Figure 64 Netvault Device Management...
- Page 12 Figures Quantum TC2201E User’s Guide...
- Page 13 Report LUNs Parameter List ... 99 Table 6 Format of LUN Inquiry Command ... 99 Table 7 Format of EVPD Page 0x80 ... 100 Table 8 TC2201E LUN Inquiry Data... 100 Table 9 Vendor Unique Commands... 102 Table 10 Main menu ... 105 Table 11 Configuration menu...
- Page 14 Adding a iSCSI Host ...133 Deleting a Host...134 Editing Host List for iSCSI Port ...135 Utility Settings...137 Trace Settings ...138 Trace Settings, Page 2 ...139 Trace Settings, Page 3 ...140 Trace Settings, Page 4 ...141 Trace Settings, Page 5 ...142 Quantum TC2201E User’s Guide...
- Page 15 SCSI Command Tracking Menu ... 150 Table 56 Trace Dump Menu ... 151 Table 57 Advanced Software Licences Menu ... 152 Table 58 Advanced Licensed Features Menu ... 153 Table 59 Download Firmware Menu ... 154 Quantum TC2201E User’s Guide Tables...
- Page 16 Tables Quantum TC2201E User’s Guide...
- Page 17 This document is written for operators of the TC2201E router. Audience This document explains how to use the TC2201E router. Purpose This document is organized as follows: Document Organization • Chapter 1, • Chapter 2, Getting the installation of the router.
- Page 18 Notes emphasize important information related to the main topic. Cautions indicate potential hazards to equipment and are included to prevent damage to equipment. Warnings indicate potential hazards to personal safety and are included to prevent injury. Quantum TC2201E User’s Guide Sizes, provides information...
- Page 19 Englewood, CO 80112 (800) 854-7179 or (303) 397-2740 Quantum company contacts are listed below. Contacts Quantum Corporate Headquarters To order documentation on the Quantum PX500 Series libraries or other products contact: Quantum Corporation P.O. Box 57100 Irvine, CA 92619-7100 (949) 856-7800...
- Page 20 Quantum Home Page Visit the Quantum home page at: http://www.quantum.com Customer Support The Quantum Customer Support Department provides a 24-hour help desk that can be reached at: North/South America: Asia/Pacific Rim: Europe/Middle East/Africa: Send faxes for the Customer Support Department to:...
-
Page 21: Chapter 1 Introduction
The Quantum TC2201E iSCSI router provides bi-directional connectivity between two iSCSI networks, and two Narrow/Wide Fast/Ultra160 LVD/SE SCSI buses. Supported devices include: • Initiator Devices – iSCSI hosts • Direct Access Devices – RAID controllers, Disk drives, JBODs • Sequential Access Devices – Tape drives •... -
Page 22: Operation Indicators
Reset Button that is used to manually force a reboot of the TC2201E. For proper operation of the TC2201E, cable connections on the back panel should remain securely in place. -
Page 23: Figure 3 Tc2201E Leds
Ethernet port activity on this management port. How the TC2201E Works The TC2201E is a router that translates the iSCSI protocol to and from the SCSI Protocol—transparently transferring commands, data, and status information—so that devices and hosts can communicate with each other. -
Page 24: Figure 5 Information Processing
5 of the process. 1 A iSCSI host issues a command. The iSCSI host encapsulates the command in the iSCSI protocol and sends the packet to the TC2201E. 2 The iSCSI controller in the TC2201E receives the packet, interprets the iSCSI information, and places the packet in buffer memory. -
Page 25: Figure 6 Flow Of Data And Responses
6 Data flows between the iSCSI host and SCSI target through payload buffers (see 7 Response information flows from the SCSI target back to the iSCSI host (see Figure 6 Flow of data and responses figure figure Quantum TC2201E User’s Guide Chapter 1 Introduction Processing SCSI Information... -
Page 26: Chapter 1 Introduction Lan-Free Backup And Restore
LAN and onto a dedicated storage network. The TC2201E supports LAN-free backup/restore environments (see Figure 7 LAN-free backup TC2201E Features The TC2201E provides the following iSCSI features: iSCSI Features • Dual iSCSI ports (10/100/1000 baseT Ethernet) •... -
Page 27: Scsi Bus Features
Field-updateable firmware TC2201E Benefits The Quantum TC2201E is designed to connect SCSI devices into an iSCSI network. The Quantum TC2201E is neatly packaged in a 1U form factor with two 1 Gb/s iSCSI ports and two LVD/SE SCSI buses. SCSI buses automatically negotiate for Fast, Narrow, Wide, and up to Ultra160 SCSI. -
Page 28: Enterprise Class Performance
Manager (VM) software. “Store-and-forward” allows configuration files Complexity and TC2201E operational settings to be saved and copied to other like routers, reducing redundant setup tasks. Using VM, service professionals and end users can configure a TC2201E with simple “point and click”... -
Page 29: Industry Leading Inter Operability
Quantum has a proven history of industry leading inter operability, Industry Leading which we incorporate into all our products. Quantum and its partners Inter Operability have tested thousands of different configurations, discovering and resolving many troublesome inter operability ability problems. -
Page 30: Non-Operating Environment
Chapter 1 Introduction TC2201E Specifications The non-operating environment of the TC2201E is: Non-operating Environment • -40 to +65°C • 10 to 90% Relative Humidity (non-condensing) The power requirements for the TC2201E are: Power • 100 - 240 VAC, Auto Sensing •... -
Page 31: Chapter 2 Getting Started
This chapter describes how to install the TC2201E and what to consider when unpacking the unit for the first time. The TC2201E can be set up as either a desktop or rack installation and connected to various types of devices. -
Page 32: Unpacking The Box
Chapter 2 Getting Started Location Location The TC2201E can be placed on a desktop or mounted in a standard 19- inch rack depending on the specific requirements of the installation. The operating environment should meet the requirements found in Physical attach the stick-on feet to the bottom of the unit. -
Page 33: Mounting The Tc2201E In A Rack
Mounting the TC2201E in a Rack Before beginning installation, review the following installation procedure. When familiar with the installation procedure, follow the steps indicated to mount the TC2201E into a standard 19” rack using the provided mounting materials, which include: •... -
Page 34: Figure 8 Installing Cage Nuts
Chapter 2 Getting Started Mounting the TC2201E in a Rack Figure 8 Installing Cage Nuts 5 Locate the front of the ear brackets, as shown in figure 9 below. Figure 9 Locating front of ear brackets Quantum TC2201E User’s Guide... -
Page 35: Figure 10 Attaching The Ear Brackets
6 Attach the ear brackets to the TC2201E, using two of the #6-32x.312 Phillips screws on each side (as shown in the front of each bracket next to the end of the TC2201E that will be facing out of the rack (see Step 7 for more information). Tighten the screws securely. -
Page 36: Figure 11 Mounting At Front Of Rack
Chapter 2 Getting Started Mounting the TC2201E in a Rack Figure 11 Mounting at Front of Rack Quantum TC2201E User’s Guide... -
Page 37: Figure 12 Mounting At Back Of The Rack
Figure 12 Mounting at Back of the Rack Once the TC2201E is installed, you are ready to connect it to the other system components. Interfaces and Connections There are four types of interfaces to the TC2201E: • iSCSI • SCSI •... -
Page 38: Iscsi Connections
Product ID labels Figure 14 WWN/MAC ID label Before connecting the TC2201E to other iSCSI devices, it is important to understand the configuration requirements of the environment to which iSCSI Connections it will be connected. Failure to correctly configure an iSCSI device may impair the operation of the network to which it is attached. -
Page 39: Scsi Connection
LVD/Single-Ended buses. Two VHDCI 68-pin D-shell, P-type connectors are located on the rear panel of the unit, allowing the unit to be attached at the end of up to two SCSI buses. The TC2201E must always be installed at the end of SCSI buses. -
Page 40: Figure 16 High Density Scsi Cables
Warning: Caution: Caution: Any SCSI cables used with the TC2201E series product must meet SCSI 2 standards and must be LVD rated (specifically low noise cabling). The cables should be rated at 24 Ohm impedance and should have a VHDCI 68pin.8mm D-shell/P-type to Standard 68pin SCSI D-shell connector at the... -
Page 41: Figure 17 Tc2201E Scsi Connection
TC2201E. The type of connector at the other end of the cable will be dependent on the device being connected. Warning: Note: To connect the TC2201E to a SCSI bus: 1 Power off the SCSI devices on this bus. -
Page 42: Ethernet Management Connection
Connection utilizing a terminal emulator. The baud rate, data bits, stop bits, parity, and flow control of both the TC2201E and the host system must use the same settings. Refer to management. -
Page 43: Setting Up Serial Port Communications
To set up serial communications with the TC2201E: 1 Leave power to the TC2201E turned off until you have set up the serial port communications on your host terminal. 2 Plug the serial cable into one of the host computer’s serial ports (COM1 or COM2), and then plug the other end of the serial cable into the TC2201E’s serial port. -
Page 44: Connecting The Power Cable
6 Proceed to the following instructions on connecting the power to the TC2201E. The power supply used with the TC2201E supports 100 - 240 VAC (Auto Connecting the Sensing), but the correct type of power cable needed for your installation Power Cable should still be verified. -
Page 45: Figure 20 Tc2201E Power Switch And Connector
Configuring the TC2201E The TC2201E can be configured in a variety of ways. The following are general procedures for setting up basic operation. Not all of these settings will apply to every environment, but these guidelines should provide the fundamental steps for configuring the TC2201E. - Page 46 TC2201E. 3 To begin configuration of the TC2201E, enter the IP address of the Ethernet management port into the web browser address field and...
-
Page 47: Configuring The Tc2201D Using The Command Line Interface
8 Select the SCSI Bus page. SCSI ID 7 is the default SCSI Initiator ID for each of the TC2201E’s SCSI buses. If any devices attached to a TC2201E bus are using SCSI ID 7, then that bus's Initiator ID must be changed. To change a bus's Initiator ID: Select the desired bus from the TC2201E GUI or the SCSI Bus submenu. -
Page 48: Chapter 2 Getting Started Save Backup Version Of Configuration
11 Select menu option TC2201E will once again display the main menu. 12 If the TC2201E does not see all of the devices expected, repeat step 3 above, and check that the initiator ID(s) are set to a unique value for the selected bus. -
Page 49: Advanced Configuration Options
CHAP (Challenge-Handshake Authentication Protocol) provides a secure procedure for connecting to systems, as follows: 1 After a link is made, the TC2201E sends a challenge message to the connection requestor. The requestor responds with a value obtained by using a one-way hash function. -
Page 50: Scsi Configuration
State Change Notifications. To use iSNS with the TC2201E, simply enable the TC2201E as a client and then enter a DNS name or IP address for up to three iSNS servers. -
Page 51: Chapter 3 Quantum Visual Manager
Quantum Visual Manager This chapter describes the Quantum Visual Manager (QVM). The current configuration and operating status of the TC2201E can be accessed from any standard Web browser, after the user logs in with the appropriate username and password. Information is presented in HTML format in accordance with the W3C specification for HTML 3.2. -
Page 52: Accessing Visual Manager
DHCP option. Note: If you do not know the IP address of the TC2201E, then connect to the TC2201E using the serial (RS-232) connection (a 3-pin serial cable is included with the TC2201E). Current settings can be viewed and changed from the Ethernet Configuration Menu of the serial interface. - Page 53 Settings. 7 Upon successful login, the user has initiated a "session", and has full access to the TC2201E QVM for the duration of the session. A session ends when the user exits all instances of the web browser. Log-in will be required again, via the TC2201E's home page, to initiate a new session.
-
Page 54: Chapter 3 Quantum Visual Manager Making Changes Via Visual Manager
Select the Submit button to send changes from the Web browser to the TC2201E. Other than dynamic mapping changes, configuration changes will not take effect until the next time the TC2201E reboots. The unit can be forced to reboot by selecting the Reboot option from the Main Menu. -
Page 55: Figure 21 Visual Manager Home Page
Left-clicking on a port opens a menu for making changes to settings for that particular port. The interactive TC2201E image is available for most menus. (figure 22) of the TC2201E is shown on the home page. Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Making Changes via Visual Manager... -
Page 56: Chapter 3 Quantum Visual Manager Main Menu
Chapter 3 Quantum Visual Manager Main Menu Figure 23 Main Menu The main menu on the left side of the TC2201E home page provides a list of menu items that are links to various TC2201E functions, information, and other menus. -
Page 57: Figure 24 System Page
Figure 24 System Page This page shows system status and allows configuration of standard system components and ports. Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 58: Main Menu > System > Serial Port Settings
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page shows the current baud rate for the serial port and allows it to System > Serial be changed. Port Settings Figure 25 Serial port settings page To make any changes, modify the entries by using the field’s down arrow and selecting a choice. -
Page 59: Main Menu > System > Iscsi Settings
Submit button. iSCSI Target Settings • Authentication can be toggled between Enabled and Disabled. The default setting is Disabled. When set to Enabled, CHAP authentication for iSCSI is enabled. Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 60: Figure 27 Iscsi Authentication Settings Page
Chapter 3 Quantum Visual Manager Main Menu • Setup Authentication button opens the iSCSI Authentication page. This page consists of entry fields for CHAP name, Initiator Secret, and Target Secret, as well as a field for Target CHAP Name. Figure 27 iSCSI... - Page 61 Portal Group Settings can be toggled between the following two settings: • Use one portal group for both ports: By default, the TC2201E is set to use one Portal Group for both ports, which enables failover capability between the two iSCSI ports.
-
Page 62: Main Menu System Isns Settings
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page allows for configuration of iSNS settings. System > iSNS Settings Figure 28 iSNS Settings Page iSNS servers maintain information about iSCSI clients and will respond to iSNS protocol queries and requests, and initiate iSNS protocol State Change Notifications. - Page 63 To use iSNS, enable the TC2201E as a client and then enter a DNS name or IP address for up to three iSNS servers. To make changes or to discontinue communication with a server, change or clear the identification field(s), select the TC2201E to activate changes.
-
Page 64: Main Menu System User Settings
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page allows for setup of security options for username and System > User password. Settings Figure 29 User settings page Security settings include the The administrator user name and password should be unique and kept confidential. - Page 65 In the event that either or both the user name and password Note: are forgotten, it is possible to reset the user name and password to their default values by resetting the TC2201E to factory defaults from the Command Line Interface using the serial port (see...
-
Page 66: Main Menu System Real Time Clock Configuration
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page allows for set up of the date and time. System > Real Time Clock Configuration Figure 30 Real Time Clock Configuration Page To make any changes, modify the entries as described below and then select the •... -
Page 67: Main Menu System Factory Settings Reset
Time Settings 24 hour clock. Note: Main Menu > This page allows the TC2201E to be reset to the factory default settings. System > Factory The TC2201E must be rebooted before the reset settings will take effect. Settings Reset Note: Note: are for setting the hours, minutes, and seconds. -
Page 68: Figure 31 Factory Settings Reset Page
When this option is selected, a confirmation message will appear to verify the selection. If a response of current TC2201E activities will be disrupted while the unit resets the current configuration to the factory defaults and saves those options to FLASH memory as the current configuration. -
Page 69: Main Menu Ethernet
Main Menu > This page provides status and links for Ethernet and iSCSI port configuration pages. Ethernet Figure 32 Ethernet Settings Page Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 70: Figure 33 Host Name Page
Chapter 3 Quantum Visual Manager Main Menu To make any changes, modify the entries as described below and then select the • Hostname long. To change this entry, select hostname from the Ethernet Menu to open the Hostname page. From the hostname page, changes to the hostname can be entered into the Desired Hostname field. -
Page 71: Figure 34 Ethernet Port Configuration Page
IP Gateway connected to the TC2201E. The default setting is 0.0.0.0. is the IP address of the TC2201E. The default setting for is the IP subnet mask for the TC2201E. The default is the IP address of the gateway for the Ethernet network Quantum TC2201E User’s Guide... - Page 72 Protocol (DHCP). When enabled, the TC2201E will retrieve a dynamic IP address from a DHCP server located on the Ethernet network that the TC2201E is connected to. The default setting is Enabled. If DHCP is changed from Disabled to Enabled, it is necessary to reboot the TC2201E before an IP address will be requested from the DHCP server.
-
Page 73: Figure 35 Ethernet Overrides Settings Page
Note: • Current MAC address address configured for the TC2201E. The MAC address is a hardware address that uniquely identifies each physical node on an Ethernet network. While the MAC address can be changed, it is highly recommended not to change this address. -
Page 74: Main Menu > Scsi Bus
Chapter 3 Quantum Visual Manager Main Menu Main Menu > SCSI This page allows for viewing the current SCSI attributes and settings for buffered tape writes. Figure 36 SCSI Bus Page To make any changes, modify the entries as described below and then... -
Page 75: Figure 37 Scsi Bus Configuration Page
However, the user should be aware this delay is added to the time it takes for the TC2201E to reboot and for QVM to be active again. The default setting is 2 seconds. must be assigned an Initiator ID. This ID should be enables/disables device discovery on this SCSI bus. -
Page 76: Figure 38 Scsi Overrides Settings Page
Chapter 3 Quantum Visual Manager Main Menu • Bus Reset on Boot devices after an initial power up or reboot of the TC2201E. The default setting is • Override Settings storage devices that require special consideration during setup of the TC2201E. -
Page 77: Figure 39 Scsi Target Overrides Settings Page
SCSI bus. The default setting is Enabled. can be assigned an Initiator ID, which is the ID Override settings should not be changed except by or under the direction of an authorized Quantum technician enables/disables the option for negotiation on a enables/disables the option for synchronous Quantum TC2201E User’s Guide... - Page 78 Chapter 3 Quantum Visual Manager Main Menu • Alternate Block Size which is the common block size used in AS/400 environments. The default setting is disabled. • Ultra SCSI 3 Negotiation selected Target ID. This feature is useful for solving certain...
-
Page 79: Main Menu > Scsi Bus > Buffered Tape Writes
Also, status is not returned until the device completes the command. For instance, when a synchronizing command is sent to a drive, such as can be enabled or disabled. The default setting is Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... - Page 80 Maximum Writes Outstanding writes that can be buffered. Any additional writes beyond the maximum level allowed will be sent to the storage device without using buffering, but these writes may also be subsequently buffered when completion notices for earlier writes are received.
-
Page 81: Main Menu Discovery
SCSI configuration pages. Caution: Discovery should not be used when SCSI command or I/O operations are in progress. Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 82: Main Menu Iscsi Mapping
Chapter 3 Quantum Visual Manager Main Menu Main Menu > iSCSI This page shows all available iSCSI hosts with maps that have been assigned to the current port. Maps and hosts may be added, edited, or Mapping deleted. To choose a different port, select from the list of ports shown in the menu under the heading Mapping Menu by left-clicking on the desired port. - Page 83 Auto Assigned maps cannot be cloned. • Select the Activate Mapping Changes the current map without rebooting the TC2201E. These changes are made effective immediately after being submitted. Before activating any port mapping changes, it is strongly Caution:...
-
Page 84: Figure 43 Select Host Page
The following shows the select current map page when the Select Current Host settings are saved to memory when the selected but are not activated until either the button is selected or the TC2201E is rebooted. Changes button is selected. -
Page 85: Figure 44 Select Current Map Page
To fill the map, select the fill option from the pull-down list and then select the current mappings. button. When the map is filled, the menu shows the Fill Map Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu Clear Map... - Page 86 Chapter 3 Quantum Visual Manager Main Menu • To remove all gaps, or unfilled entries, from this map, select the Remove Gaps option also renumbers all Indexes in sequential order starting with Index 0. Note: • To delete a specific map entry, select an Index from the pull-down list under Delete Map Item.
-
Page 87: Main Menu Statistics
Select SCSI Statistics from the Statistics Menu on the left and then select continue logging any new statistics. button to clear all current statistics for the selected buses and Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 88: Main Menu Utilities
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page allows access to the FTP utility and the settings and information for the event log and various trace options. Select from the Utilities list of menu options shown under the heading Utilities by left-clicking on the desired selection. -
Page 89: Main Menu > Utilities > Ftp Utility
Chapter 3 Quantum Visual Manager Main Menu This page provides access to an FTP Utility. Main Menu > Utilities > FTP Utility Quantum TC2201E User’s Guide... -
Page 90: Figure 47 Ftp Utility Page
Chapter 3 Quantum Visual Manager Main Menu Figure 47 FTP utility page Note: The FTP Utility requires the use of a JAVA applet and will prompt for permission to install the applet, if needed. If you receive this prompt, Internet access is required to verify the signature for the FTP applet and to download the JAVA applet plug-in for your browser. - Page 91 Grant this session becomes available for use. To use the FTP Utility, do the following: 1 1. Fill in the User Name, Password, and IP Address of the TC2201E. 2 2. Select the button to establish an FTP session with the Connect TC2201E.
-
Page 92: Main Menu Utilities Trace Settings
Settings Figure 48 Trace settings page Select the Page, for trace logging of the TC2201E. Select the which appears similar to the Basic Trace Settings Page but offers an expanded view with more trace options. button to submit changes for the Basic Trace Settings... -
Page 93: Figure 49 Advanced Trace Settings Page
For both the Basic and Advanced pages, the default setting for each trace setting is Min (track non-error conditions) but any or all settings can be changed to Errs (track error conditions) or All (track both error and non- Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu... -
Page 94: Traces
The Current Traces, Previous Traces, and Last Assert Traces menu options show the indicated trace information. Current Traces shows data TracesPrevious since the TC2201E was last booted. Previous Traces shows data from the TracesLast Assert last boot cycle. Last Assert Traces shows data from the last assertion. -
Page 95: Figure 50 Current Tracespage
Figure 50 Current TracesPage Trace buffers can be cleared by selecting either the option or the option. Clear Assert Traces Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu Clear Current Traces... -
Page 96: Main Menu > Utilities > Clear Current Traces
When this option is selected, a confirmation message will appear to verify the selection. If a response of Yes is given to the confirmation message, the unit will clear the current trace buffer. Current TC2201E activities will not be disrupted by this operation. Select the your choice. -
Page 97: Main Menu > Utilities > Clear Assert Traces
When this option is selected, a confirmation message will appear to verify the selection. If a response of Yes is given to the confirmation message, the unit will clear the assert trace buffer. Current TC2201E activities will not be disrupted by this operation. Select the your choice. -
Page 98: Main Menu Utilities Event Log Settings
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page allows set up of Event Log Settings. Utilities > Event Log Settings Figure 53 Event Log Settings Page To make any changes, modify the entries as described below and then select the Select from the Event Log settings shown. - Page 99 The default setting is All Events Logged. So that event logging is accurate, be sure to correctly set the Note: clock and date in the Real Time Clock Configuration menu. Quantum TC2201E User’s Guide Chapter 3 Quantum Visual Manager Main Menu...
-
Page 100: Main Menu Utilities Event Log
Chapter 3 Quantum Visual Manager Main Menu Main Menu > This page displays the Event Log. Utilities > Event Figure 54 Display Event Log Page Quantum TC2201E User’s Guide... -
Page 101: Main Menu Utilities Clear Event Log
When this option is selected, a confirmation message will appear to verify the selection. If a response of Yes is given to the confirmation message, the unit will clear the event log. Current TC2201E activities will not be disrupted by this operation. Select the choice. -
Page 102: Figure 56 Scsi Command Tracking
Main Menu > This page provides options for setting up and logging SCSI commands Utilities > SCSI that are received or transmitted by the TC2201E. Results are displayed in the Host/Device ID Table. Command Tracking While the TC2201E’s current, previous, and last assert trace data does... - Page 103 SCSI Command Tracking can be toggled to ON or OFF. When toggled ON and Submitted, all SCSI commands received or transmitted to or from the TC2201E are then logged in the SCSI Commands section shown on this screen. When set to OFF (and Submitted), no SCSI commands are logged.
-
Page 104: Main Menu Features
Chapter 3 Quantum Visual Manager Main Menu Main Menu > The features page is where advanced software licensed features can be enabled. Features Figure 57 Features Page To enable an advanced software licensed feature, enter a key number in the field and select the... -
Page 105: Main Menu Report
Chapter 3 Quantum Visual Manager Main Menu Main Menu > The report page presents a consolidated view of all system information. Report Figure 58 Report page Quantum TC2201E User’s Guide... -
Page 106: Main Menu Reboot
When this option is selected, a confirmation message will appear to verify the selection. If a response of Reboot current TC2201E activities will be disrupted while the unit restarts itself. The last submitted configuration changes will also take effect after the TC2201E powers on again. Select the choice. -
Page 107: Chapter 4 Troubleshooting
Indicators The TC2201E is equipped with rear panel LED indicators for monitoring overall unit status. Quantum TC2201E User’s Guide... -
Page 108: Chapter 4 Troubleshooting Indicators
When this indicator is amber, this indicator shows that the TC2201E detects a fault condition. Faults can occur as a result of Power On Self Test (POST) failure or operational failures. -
Page 109: Basic Verification
• Device ID—Each device on a SCSI bus must have a unique ID. Also check the configured ID’s for the TC2201E to verify these are not in use by other devices on the same SCSI bus. Quantum TC2201E User’s Guide... -
Page 110: Verify Iscsi Connection
• SCSI Devices—Verify that the SCSI devices on a particular SCSI Bus can be seen in the by the TC2201E. Check the Discovery page to verify visibility of devices. If the TC2201E can not see the devices, verify SCSI configuration, cabling, and termination. -
Page 111: Verify Mapping
HBAs typically come with utility programs to view or change their Verify HBA Device configurations. Driver Information If you are unable to resolve an issue, contact your authorized service representative and ask for customer support. Customer Support Quantum TC2201E User’s Guide Chapter 4 Troubleshooting Basic Verification... - Page 112 Chapter 4 Troubleshooting Basic Verification Quantum TC2201E User’s Guide...
-
Page 113: Pin To Db-9 Serial Pin Assignments
The pin assignments given for the 3-pin serial connection are in reference to the serial receptacle on the rear panel of the TC2201E. Use an RS-232 null modem cable to connect the TC2201E to the host system. Table 1 RJ-11 Pin Pin No. -
Page 114: Appendix A 3-Pin To Db-9 Serial Pin Assignments
Appendix A 3-Pin to DB-9 Serial Pin Assignments In conjunction with the pin assignments provided for the 3-pin receptacle on the rear panel of the TC2201E, following are the corresponding pin out assignments for a DB-9 serial connector used to connect the other end of the serial cable to a terminal, or a computer running terminal emulation software. -
Page 115: Ethernet Pin Assignments
RJ-45 Ethernet Pin Assignments The pin assignments given for the RJ-45 Ethernet connection are in reference to the Ethernet receptacle on the back panel of the TC2201E. The TC2201E Ethernet connection supports the IEEE specifications for 10BASE-T and 100BASE-TX Ethernet standards. - Page 116 RJ-45 Ethernet Pin Assignments Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 RJ-45 modular receptacle pin assignments Receive In + Connection Connection Receive In - Connection Connection 1 2 3 4 5 6 7 8 Quantum TC2201E User’s Guide...
-
Page 117: Inband Scsi-3 Commands
The TC2201E supports a set of SCSI-3 commands that can be received inband over iSCSI. When received by the TC2201E, these commands are then executed by the TC2201E itself. When using SCSI-3 commands to access general management features, the commands can be sent to device LUNs that are mapped through the TC2201E. -
Page 118: Appendix B Inband Scsi-3 Commands General Commands
Following is a description of a general-use SCSI-3 command. For more information about the other general-use commands, please contact your service representative. The TC2201E supports the Report LUNs command. The Report LUNs Report LUNs command will return a list of Logical Unit Numbers (LUNs) that can Command receive commands. -
Page 119: Inquiry Command
LUN list length (LSB) Reserved Reserved Reserved Reserved LUN list First LUN Last LUN The LUN list length is the number of LUNs times 8. Operation Code (12h) Reserved Page Code or Operation Code Quantum TC201E User’s Guide General Commands EVPD... -
Page 120: Table 7 Format Of Evpd Page 0X80
Appendix B Inband SCSI-3 Commands General Commands The TC2201E returns the LUN Inquiry Data as defined in Table B-5. EVPD Page 0x80 If the EVPD bit is set and the Page Code is 0x80 the unit serial number page is returned. The format of this page is shown in... - Page 121 Product ID “TC2201E router” Revision Level “XXXXX” The TC2201E will only reply to a SCSI Inquiry when using 8-byte LUN field of 0x00's. The Revision Level comes from the last four characters of the build Note: string, which appears in the headings for most menu screens.
-
Page 122: Vendor Unique Commands
Appendix B Inband SCSI-3 Commands Vendor Unique Commands Vendor Unique Commands The TC2201E supports a set of vendor unique commands. provides an overview of these commands. For more information about these vendor unique commands, please contact your service representative. Table 9... -
Page 123: Appendix C Using The Command Line Interface
Using the Command Line This chapter describes specific configuration options available from the Command Line Interface (CLI). The TC2201E allows the user to access many configuration settings through the CLI. Among these settings are: • Baud rate of the serial port •... -
Page 124: Power Up Messages
(See “Chapter 2, , Setting Up Serial Port Communications”) or the Telnet utility for Telnet sessions. A series of power-up self tests are performed while the TC2201E starts (which can take up to 2 minutes), and messages related to these tests will be visible from the serial port. -
Page 125: Table 10 Main Menu
Select 4 to reboot the TC2201E. A confirmation message will appear verifying you want to do this. If you enter N for No, you are returned to the System Utilities menu. If you enter Y for Yes, the TC2201E will restart. This option is further described later in this chapter. -
Page 126: Perform Configuration
Perform Configuration Perform Configuration The Perform Configuration menu allows the administrator to configure the various options on the TC2201E. For most configuration changes to take effect, you must reboot the TC2201E. Note: Table 11 Configuration menu X.XX.XXXX 1) User Settings... -
Page 127: User Settings Configuration
In the event that either or both the user name and password are forgotten, it is possible to reset the user name and password to their default values by resetting the TC2201E to factory defaults. Note that resetting to factory defaults from the serial port will also reset all other configuration settings to factory defaults, as well as erase all current maps. -
Page 128: Ethernet Configuration
Ethernet MAC address, DNS settings, and Ethernet MTU size. Baud Rate Configuration Menu X.XX.XXXX XXXXXX 07/26/2005 9600 19200 38400 57600 5) * 115200 X) Return to previous menu The asterisk (*) symbol indicates the current setting for the baud rate. Quantum TC2201E User’s Guide XXXXXXXXXXXXXX 08:56:22... -
Page 129: Table 14 Figure 7-5: Ethernet Configuration Menu
Select 1 to toggle the DHCP setting. This setting enables/disables support for Dynamic Configuration Protocol. When enabled, the TC2201E will retrieve a dynamic IP address from a DHCP server located on the Ethernet network that the TC2201E is connected to. - Page 130 Ethernet port is 1.1.1.1. The default setting for iSCSI Port 0 is 169.254.1.1. The default setting for iSCSI Port 1 is 169.254.1.2. • Select 3 to change the IP subnet mask for the TC2201E. The default for this setting is 255.255.255.0. •...
-
Page 131: Table 15 Change Dns Settings Menu
XXX.XXX.XXX.XXX where each XXX represents an integer in the range of 1 to 255. Select 2 to change the DNS Domain. The text “server.company.com” shown above is an example of how a DNS Domain name could appear. Quantum TC2201E User’s Guide Perform Configuration... -
Page 132: Iscsi Configuration
Host settings can be set in the Microsoft iSCSI Initiator for Windows systems, or from the iSCSI initiator available in Linux or other operating systems. iSCSI Configuration Menu XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 : Enabled : Disabled Quantum TC2201E User’s Guide... -
Page 133: Table 17 Authentication Chap Records Configuration Menu
Select 4 to change the settings for a device currently using CHAP authentication. Select 5 to delete all records for CHAP authentication. Select 6 to setup a Target device CHAP name. Target CHAP names are 1-18 characters. Quantum TC2201E User’s Guide Perform Configuration... -
Page 134: Table 18 Isns Server Configuration Menu
• Select 3 to toggle the iSNS client between Enabled and Disabled. The default setting is Disabled. When enabled, the TC2201E will function as an iSNS client and will initiate transactions with iSNS servers using the iSNSP. The iSNS client is a process that is co-resident in the TC2201E, and which can register device attribute information with the iSNS server. -
Page 135: Table 19 Iscsi Portal Group Configuration Menu
• • Select 5 to setup or change Portal Group configurations. By default, the TC2201E is set to use one Portal Group for both ports, which effectively enables failover capability between the two iSCSI ports. Table 19 iSCSI Portal Group Configuration... -
Page 136: Parallel Scsi Configuration
5) Edit SCSI Target Override Settings X) Return to previous menu Command, <enter> for next SCSI bus > key to toggle the current menu to the next SCSI bus. Enter Quantum TC2201E User’s Guide XXXXXXXXXXXXXX 08:56:22 : 07 : Enabled... - Page 137 • Select 4 to set the discovery delay time for SCSI devices. This is the time the TC2201E waits after a power-up or reboot before starting to discover SCSI devices. This value should be set to no less than 250ms, according to the SCSI standard for Reset-to-Selection Time.
-
Page 138: Table 21 Scsi Initiator Menu
This should be a unique ID on the bus. The default setting is 7. The user must enter a integer value in the range of 0-15 prior to saving the configuration to the TC2201E. • Select 2 to enable/disable an alternate SCSI Initiator ID. -
Page 139: Table 22 Scsi Target Overrides Menu
X) Return to previous menu Following are descriptions for each of the settings: • Wide Negotiation wide SCSI bus. Normally, override settings should not be changed except when directed to do so by an authorized Quantum technician. XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Enabled... -
Page 140: Parallel Scsi Buffered Tape Write Configuration Menu
Buffered Tape Writes Maximum Writes Outstanding Maximum Bytes Outstanding 1) Enable/Disable Buffered Tape Writes 2) Set Maximum Writes Outstanding 3) Set Maximum Bytes Outstanding X) Return to previous menu Quantum TC2201E User’s Guide XXXXXXXXXXXXXX 08:56:22 : Enabled : 1024 KB... - Page 141 Select 2 to set Maximum Writes Outstanding. This setting determines the maximum number of writes that can be buffered. Any additional writes beyond the maximum level allowed will be sent to the storage device without using buffering, but these writes may also be subsequently buffered when completion notices for earlier writes are received.
-
Page 142: Device Mapping
When the iSCSI Portal Groups setting is configured to use separate ports, pressing the Device Mapping Main Menu XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Enter Quantum TC2201E User’s Guide key will have no effect on this Enter key will toggle between iSCSI Port... -
Page 143: Table 25 Select Current Map
“current” map. The map selected from this list will be the one used by the TC2201E to direct data to the appropriate targets and initiators. -
Page 144: Table 26 Add A Map
The screen will ask for confirmation before deleting the map. After the map has been deleted, the default map for the current port becomes the current map. Maps with names ‘Auto Assigned’ may not be removed. Add Current Map XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Quantum TC2201E User’s Guide... -
Page 145: Table 27 Delete Current Map
X) Return to previous menu Command > Note: Map Edit Menu XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Enter the number of one of the available selections or enter ‘X’ to exit to the Device Mapping Main Menu. Quantum TC2201E User’s Guide Perform Configuration... -
Page 146: Table 29 Edit Map Name
Select ‘X’ to return to the Map Edit Menu. Select ‘A’ to add a new entry to the map or ‘D’ to delete an already existing entry in the map. Select ‘R’ to get rid of the gaps in the map. Quantum TC2201E User’s Guide... -
Page 147: Table 30 Adding An Iscsi Port Entry
The user can create an empty map or use an existing map to pre-enter devices that are not yet online. To perform this operation, the user has to Device List XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 State | Description 0 | TAPE | ONLINE | QUANTUM Quantum TC2201E User’s Guide Perform Configuration DLT8000 023C |... -
Page 148: Table 32 Deleting An Entry
Target ID and LUN ID for the device. Target ID must already be defined in the SCSI Configuration. Otherwise, adding a device will not be permitted. When creating a device that does not exist, it will be displayed with ‘Down’ status. Quantum TC2201E User’s Guide... -
Page 149: Figure 61 Clear All Entries From Current Map
‘current’ map. Devices marked as ‘DOWN’ will not be mapped. After this operation completes, the Edit Map Entries screen will appear. When deleting multiple LUNs, the user can list the LUNs to delete in a comma or space delimited format. Quantum TC2201E User’s Guide Perform Configuration... -
Page 150: Table 34 Fill Current Map
Initially all hosts are associated with an Auto Assigned map. The following is an example of an iSCSI host list: Clone Current Map XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Quantum TC2201E User’s Guide... -
Page 151: Table 36 Iscsi Host List
Entering a host number index opens the iSCSI Host Info Display, where the selected host can be associated with the current map. Host List Edit Display XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Initiator iSCSI Name Quantum TC2201E User’s Guide Perform Configuration... -
Page 152: Table 37 Iscsi Host List
Select ‘A’ to add a host to the list. The user will be prompted to enter the desired Host Name and iSCSI Initiator Name. Duplicate hosts won’t be added to the list. iSCSI Host Info Display XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Quantum TC2201E User’s Guide... -
Page 153: Table 38 Adding A Iscsi Host
For example, if the domain name were “example.com”, then the reverse domain name would be “com.example”. The Quantum TC2201E does not include iSCSI Initiator software. For additional details, contact the operating system provider. Quantum TC2201E User’s Guide... -
Page 154: Table 39 Deleting A Host
Enter to keep old information. All of the information entered by the user will be validated. The following is an example of editing a host list for an iSCSI Port: Quantum TC2201E User’s Guide... -
Page 155: Table 40 Editing Host List For Iscsi Port
Because the entire device list may not fit on one screen, select ‘N’ or ‘P’ to go back and forth between screens displaying more maps. Select ‘X’ to return to the ‘Device Mapping Main Menu’. Host List Edit Display XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Initiator iSCSI Name Quantum TC2201E User’s Guide Perform Configuration... -
Page 156: Trace And Event Settings Configuration
If the Activate Port Mapping Changes option is not selected, the mapping changes will not take effect unless the TC2201E is rebooted. After the TC2201E reboots, the Configuration Menu will appear. -
Page 157: Table 41 Utility Settings
Trace Configuration This option allows trace levels to be set. These settings should not be modified in normal operation, as performance degradation may result. There are two pages of trace levels. XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 Quantum TC2201E User’s Guide Perform Configuration... -
Page 158: Table 42 Trace Settings
(SUK) : (SUU) : (CMM) : 7 - Notify 8 - Info 9 - Debug 10 - All Quantum TC2201E User’s Guide 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum... -
Page 159: Table 43 Trace Settings
07/26/2005 08:56:22 (ASY) : (WWW) : (SLP) : (SNS) : (RSU) : (RLM) : Quantum TC2201E User’s Guide Perform Configuration 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum... -
Page 160: Table 44 Trace Settings
Trace Settings XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 (RLK) : (RLU) : (PSD) : (PST) : (PSM) : Quantum TC2201E User’s Guide 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum... -
Page 161: Table 45 Trace Settings
08:56:22 (ISD) : (IST) : (ISM) : (ISP) : (ISR) : (ISH) : (IXT) : Quantum TC2201E User’s Guide Perform Configuration 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum 0 - Minimum... - Page 162 08:56:22 (LSD) : (LST) : (LSM) : Be sure to set the clock and date in the Real Time Clock Configuration menu so trace logging is accurate. Quantum TC2201E User’s Guide 0 - Minimum 0 - Minimum 0 - Minimum...
-
Page 163: Table 47 Event Filter Settings
• Select A to toggle reservation/release events logging. The default setting is Enabled. • Select U to send event configuration changes to the TC2201E now. Event logging captures over 2000 events and then starts overwriting the log when full. Note:... -
Page 164: Real-Time Clock Configuration
This option restores the most recently saved configuration. This can be Restore Last useful when configuration changes are made, but the user wishes to Saved return to the previously saved configured state. The changes take effect Configuration after the TC2201E has rebooted. XXXXXXXXXXXXXX 12:48:42 Quantum TC2201E User’s Guide... -
Page 165: Reset And Save Configuration To Factory Defaults
User configured values for the IP address, gateway, and subnet maskare retained after the TC2201E resets. Note that user names and passwords are NOT retained. Settings are not reset to factory defaults until the TC2201E is rebooted. System Utility Menu X.XX.XXXX... -
Page 166: System Statistics
X) Return to main menu Parallel SCSI Protocol Status Menu X.XX.XXXX XXXXXX 07/26/2005 1) Display SCSI Statistics 2) Display Attached SCSI Devices 3) Display SCSI Resource Status X) Return to previous menu Quantum TC2201E User’s Guide XXXXXXXXXXXXXX 08:56:22 XXXXXXXXXXXXXX 08:56:22... -
Page 167: Table 52 Scsi Device Display Menu
Select 2) to issue discovery for the selected SCSI bus. Select 3) to issue boot discovery (includes resets and delays). Select 4) to display all local SCSI devices. Select 5) to display local devices on the specified SCSI bus. Quantum TC2201E User’s Guide System Utilities... -
Page 168: Event Log
When this option is selected from the System Utilities menu, the Event Event Log Log Menu is displayed. Note: SCSI Resource Display XXXXXX XXXXXXXXXXXXXX 07/26/2005 08:56:22 2048 2048 2048 To get a copy of any of the event log, see Chapter 8, Using the FTP Interface. Quantum TC2201E User’s Guide... -
Page 169: View Report
1) Display event log 2) Clear event log X) Return to previous menu Time sysUpTime Event logging captures over 2000 events and then starts overwriting the log when full. Quantum TC2201E User’s Guide System Utilities XXXXXXXXXXXXXX 08:56:22 Message Starting Quantum iSNS Client, v1.0. -
Page 170: Scsi Command Tracking
Select 1 to toggle SCSI Command Tracking ON or OFF. When toggled ON, all SCSI commands received or transmitted to or from the TC2201E are logged. When OFF, these commands are not logged. When set to ON, menu options 2 thru 4 are also available from this menu. -
Page 171: Display Trace And Assertion History
3) Display Trace From Last Assertion Failure 4) Clear Current Trace Buffer 5) Clear Last Assert Trace Buffer X) Return to previous menu option will not show any data. Quantum TC2201E User’s Guide Display Trace and Assertion History appendix D XXXXXXXXXXXXXX 08:56:22... -
Page 172: Reboot
When this option is selected, a confirmation message will appear to verify the selection. If a response of Y (yes) is given to the confirmation message, current TC2201E activities will be disrupted while the unit restarts itself. The last saved configuration changes will also take effect after the TC2201E powers on again. -
Page 173: Download A New Revision Of The Firmware
1 From the Main menu, select the Download a New Revision of The Firmware option to start the download procedure. 2 When you confirm you want to download, the TC2201E will start the download process. 3 Use the Transfer → Send File option in the terminal emulator utility. -
Page 174: Table 59 Download Firmware Menu
When the download process is complete, the system verifies that the firmware image was successfully written to the FLASH memory and then reboots the TC2201E. Upon reboot, the TC2201E detects that there is a newly downloaded firmware image and copies that image to the boot sector of the FLASH and then boots with that image. -
Page 175: Appendix D Using The Ftp Interface
The TC2201E supports backup and restore of configuration settings over FTP. This allows users to maintain multiple setting configurations externally from the TC2201E and to be able to restore any of the configurations as needed. When backing up, configurations are saved from flash to a binary file. - Page 176 (ex. lcd c:\myCfg). Note: If the TC2201E is to use a static IP address, the default IP address 1.1.1.1 should be changed to an address that is appropriate for the IP network it will reside on. Note that the...
-
Page 177: Configuration Restore Procedure
4 Specify binary mode: 5 Specify the configuration’s path and filename (.cfg file) with the put command: put <path:filename.cfg> The file will transfer and the TC2201E will reboot. The TC2201E will then be using the configuration. Note: Note: Backup/Restore Configuration Settings If the TC2201E is to use a static IP address, the default IP address 1.1.1.1 should be changed to an address that is... -
Page 178: Get A Copy Of Trace Buffer Or Event Log
FTP program will store the trace file. If the TC2201E is to use a static IP address, the default IP address 1.1.1.1 should be changed to an address that is appropriate for the IP network it will reside on. Note that the... -
Page 179: Update Firmware
5 Specify the firmware’s path and filename (.dlx file) with the put command: put <path:filename.dlx> The file will transfer and the TC2201E will reboot. The TC2201E will then be using the new firmware. Note: If the TC2201E is to use a static IP address, the default IP address 1.1.1.1 should be changed to an address that is... - Page 180 Update Firmware Quantum TC2201E User’s Guide...
-
Page 181: Appendix E How To Change Block Sizes
1 Start the Windows Registry Editor program (as shown in follows: How to Change Block The block size configured within backup applications is limited to what tape drives will support. Quantum TC2201E User’s Guide Appendix E Sizes figure 62) as... - Page 182 You can also open this program at the following location: Note: %SystemRoot%\Winnt\System32\regedt32.exe Block Size Decimal Value Hex Value: Note: 64k 17 decimal 11 hex 96k 25 decimal 19 hex 128k 33 decimal 21 hex 256k 65 decimal 41 hex 512k 129 decimal 81 hex Quantum TC2201E User’s Guide...
-
Page 183: Procedure B: Veritas Netbackup
Figure 62 Registry Editor Procedure B: Veritas NetBackup Note: 1 Create a file called C:\Program Files\Veritas\NetBackup\db\config\SIZE_DATA_BUFFERS. The largest bock size support by NetBackup 5.1 for Windows is 128K or 131072 decimal bytes. Quantum TC2201E User’s Guide Procedure B: Veritas NetBackup... -
Page 184: Procedure C: Veritas Backup Exec
2 Right click on one of the tape drives detected and select Properties. 3 When the Drive Properties box appears, select the Configuration tab. 4 Specify the Block Size to be tested. The default is 64k. Quantum TC2201E User’s Guide figure 63), click on the... -
Page 185: Procedure D: Ca Brightstor Arcserve
11.0/11.1 for Windows, the block size of tape drive can be found in: HKEY_LOCAL_MACHINE \SOFTWARE \ComputerAssociate\BrightStor ARCserve Backup\Base\TapeEngine\Device\Device# Note: You need to confirm the appropriate Device# from the Device Manager in Brightstor. Quantum TC2201E User’s Guide Procedure D: CA Brightstor ARCserve... -
Page 186: Procedure E: Bakbone Netvault
4 From the Edit Drive dialog box, select the Configuration tab. 5 Set the Media block size to the desired level. Click OK when finished. figure Default is 32KB and the maximum is 2048 KB. Note: Quantum TC2201E User’s Guide 64). -
Page 187: Procedure F: Hp Data Protector
For the typical aic78xx case, it renders the following: ((17-1) * 4096) = 64k (which corresponds to 56k usable data for Data Protector) Windows provides a mechanism to support more scatter/gather elements via the Registry. Quantum TC2201E User’s Guide Procedure F: HP Data Protector... - Page 188 2 Right click on a discovered tape device and select Properties. 3 Select the Settings tab and then click on the Advanced button. 4 Select the Sizes tab and from here the block size can be modified as shown in figure 65 below. Quantum TC2201E User’s Guide...
-
Page 189: Procedure G: Commvault Galaxy
1 Using the CommVault Resource Pack CD, navigate to the folder titled setFlushBlockSize. 2 Copy SetFlushBlockSize executable to the <Galaxy Commserver install directory>\Base directory. 3 Navigate to this program SetFlushBlockSize.exe and double click to run. Quantum TC2201E User’s Guide Procedure G: CommVault Galaxy... -
Page 190: Figure 66 Commvault Galaxy
All AppTypes and the appTypes installed in the CommCell. The default chunk size that galaxy uses for granular backups is 2 Gb. The size for database backups is 8. Quantum TC2201E User’s Guide figure 66) of values - 8 KB, 16... -
Page 191: Figure 67 Commvault Galaxy (Advanced Tab)
3 Click on the Advanced tab (as shown in 4 Modify the chunk size for different application types and click OK to confirm changes. Figure 67 CommVault Galaxy (Advanced Tab) Quantum TC2201E User’s Guide Procedure G: CommVault Galaxy figure 67). - Page 192 Procedure G: CommVault Galaxy Quantum TC2201E User’s Guide...
-
Page 193: Glossary
A process of identification, usually based on a username and password. A menu item. The auto-addressing option creates a mapping table using devices discovered upon powering up or resetting the TC2201E, that is not otherwise retained by the TC2201E. Quantum TC2201E User’s Guide Glossary... - Page 194 An electrical signal configuration using a pair of lines for data transfer. The advantage of differential compared to single-ended configuration is a relative high tolerance for common-mode noise and crosstalk when used with twisted pair cables. In layman’s terms, this means longer distance. Quantum TC2201E User’s Guide...
- Page 195 An iSCSI term that includes iSCSI Arbitrated Loop, Switched Fabric, and Point-to-Point. During power up and self test, the TC2201E Fault LED comes on. After self test, if this LED remains on or comes on, the TC2201E has a problem with one of its components. During normal operation, this LED should be off.
- Page 196 Numerical identifier A menu name. It allows for generic Fibre Channel host bus adapters to access SCSI devices attached to the TC2201E using a table which is indexed by sequential LUN values. A device (usually a host system) that requests an operation to be performed by another device known as a target (usually a peripheral).
- Page 197 A table which is indexed by sequential LUN values, indicating selected BUS:TARGET:LUN devices. It is used by the TC2201E to perform Fibre Channel-to-SCSI operations by default. megabyte. (There are 8 bits in a byte.) See Management Information Base.
- Page 198 TC2201E to the specified iSCSI device. For the TC2201E, online indicates that at least one adapter in the TC2201E is active and available for access. For a SCSI adapter, online indicates the SCSI adapter is active and available for access and input/output processing.
- Page 199 A 16-bit fast/wide SE or Differential or LVD or 8-bit narrow single-ended physical connection between the TC2201E and the SCSI devices. Each SCSI adapter supports up to sixteen (for fast/ wide) or eight (for narrow) SCSI devices, including itself.
- Page 200 A SCSI device can act as an initiator or target. For SCSI-3, each SCSI device supports up to sixteen LUNs. An opening at the back of the TC2201E providing connection between the SCSI adapter and the SCSI bus. A menu name used to show the number of SCSI devices on the bus.
- Page 201 The purpose is to notify the management station of some unusual event. A status type in the FC Status Menu showing the identification of the node. A status type in the FC Status Menu showing the identification of the port. Quantum TC2201E User’s Guide Glossary...
- Page 202 Glossary Quantum TC2201E User’s Guide...
Need help?
Do you have a question about the TC2201E and is the answer not in the manual?
Questions and answers
