CDN DW2 Manual page 3

2. Slide the °C/°F switch inside the battery
compartment to select temperature reading
in Fahrenheit or Celsius.
3. Replace the battery cover.
C. Temperature Measurement – Standby Mode
In Standby Mode the max/min is always working
behind the scenes, continually storing the highest
and lowest temperatures.
1. Before placing the DW2 in the dishwasher rack,
clear the stored Max and Min values by pressing
and holding the POWER button (
The Max and Min temperatures will flash.
2. Run the dishwasher according to the manufacturer's
instructions.
3. After the dishwasher has run, remove the DW2.
4. Press the POWER button (
the LED lights for 5 seconds. The LED lights indicate
the max temperature range reached during the cycle:
Green
Yellow
Red
5. To clear the max and min values, repeat step 1. or
press and hold the POWER button (
to turn the DW2 off. The Max and Min values will
be cleared.
D. Battery Status
The Battery Status Icon ( ) appears on the display
when the batteries need to be replaced.
E. Error Messages
1. LLL indicates the temperature is below 32°F/0°C.
2. HHH indicates the temperature is above
212°F/100°C.
Note: For use in commercial dishwashers only.
Note: Remove label from display before initial use.
160 to 170°F/71 to 76.6ºC
170°F to 180°F/76.6 to 82ºC
above 180°F/82ºC
) for 2 seconds.
) briefly to illuminate
) for 7-8 seconds
3
