Atdec AD-AC-PH Installation Manual

Hinged Media Storage Panel
COMPONENT CHECKLIST
A
Bracket
(x1)
C
#10 x 16mm (5/8")
Wood screw* 16mm x 500mm
(x6)
* Professional installer to ensure appropriate fastener
length & type to suit surface where bracket is installed.
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! Failure to mount this product correctly may cause serious injury/death during or following installation.
! Exercise caution when closing tray to avoid damage to cables or components.
! This product should only be installed by professional installers of good mechanical aptitude, who fully understand these
instructions and the consequences of incorrect installation.
! Check load capacity of surface prior to installation. Failure to provide adequate structural strength for this product can result
in serious personal injury or damage to equipment. It is professional installer's responsibility to ensure suitable structural
capacity of desk (including appropriate safety factor) to support total weight of all equipment being mounted.
! This product only to be used on underside of horizontal surface.
! This product is not suitable for outdoors use.
! Do not use this product for mobile applications.
Tray
(x1)
D
M5 Flat
Hook & loop
Washer
(x12)
(5/8" x 20")
B
E
F
M4 x 12mm
Securing screw
(Optional) (x2)
Installation Guide
AD-AC-PH
REQUIRED TOOLS
• Phillips head screwdriver
• Power drill
• 3.5mm (1/8") drill bit
WEIGHT RANGE
0 - 8kg
(0 - 17.5lbs)
AD-AC-PH Page 1 of 3
