Atdec AD-TVAC-CM Installation Manual

AV Cart Camera Mount

COMPONENT CHECKLIST

Upright
Bracket
5mm 4mm
Hex Key Hex Key

IMPORTANT INFORMATION

! Please ensure this product is installed as per these installation instructions.
! Please ensure your preferred device is securely fastened to the mount prior to use or movement.
! The manufacturer accepts no responsibility for incorrect installation.
! Failure to assemble this product correctly may cause serious injury/death during or following installation.
! This product should only be installed by professional installers of good mechanical aptitude, who fully understand these
instructions and the consequences of incorrect installation.
! Do not over tighten screws.
! Two person installation is recommended.
! Product not suitable for use outdoors.
! After installation is complete check to verify that AV Cart is secure and safe for use.
! Curved monitors, deep devices (such as all-in-one PCs), VESA mounted accessories (such as mini PC brackets and mounts), and
offset VESA locations exert additional leverage that can exceed the capacity of the mount even though the monitor weight may
be within the stated range. Please contact Atdec if you would like further information.
! WARNING! Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or
toys placed on the cart may encourage a child to climb on the cart and as a result the cart may tip over on to the child.
Spanner M5x10
Screw
(x2)
Camera
Shelf
M6x10 M6
Screw Flange
(x2) Nut
Installation Guide
AD-TVAC-CM
M5x8
Screw

REQUIRED TOOLS

(x2)
• Phillips Head Screwdriver

WEIGHT RANGE

Washer
(x2)
0 - 5kg
(0 - 11lbs)
AD-TVAC-CM Page 1 of 6
