Technical specifications
Control protocols
Number of DMX channels
Input connections
Output connections
Power consumption
Supply voltage
Fuse
Dimensions (W × H × D)
Installation
Weight
Ambient conditions
50 mm
NCP
4 or 9
DMX control
Power supply
DMX control
3 × Connection for LED stripes
2 × USB
150 W
100–240 V
50/60 Hz
F1AL250V
160 mm × 220 mm × 50 mm
Holes for wall mounting
1.2 kg
Temperature range
Relative humidity
Technical specifications
160 mm
XLR chassis socket, 3-pin
Power Twist
XLR chassis socket, 3-pin
5-pin connection blocks (each with max.
50 W output)
USB 2.0, 5 V/2 A
0 °C...40 °C
20 %...80 % (non-condensing)
LED Stripe All-in-One Control
DMX Controller
