Installation and Use

! WARNING
1. All PFAS components must be selected and deemed compatible with Halo SRL-LE by Competent Person.
2. Ensure structure to which Halo SRL-LE is to be attached, and on which work is to be performed, is free of all
hazards, including, but not limited to, debris, rot, rust, sharp or abrasive edges and surfaces, and hazardous
materials.
3. Eliminate or minimize all risk of swing fall hazard.
4. Halo SRL-LE may be used in either stationary or mobile applications. For stationary applications, attach Halo
SRL-LE carabiner to selected anchorage connector, and attach snap hook to applicable harness D-ring. For LE
applications, snap hook end must be connected to harness dorsal D-ring. For mobile applications, attach
Halo SRL-LE carabiner to applicable harness D-ring, and attach snap hook to selected anchorage connector.
5. Ensure 100% tie-off will be maintained at all times, which may require the use of a back-up or
supplementary fall protection system.
SRL-LE Additional Use Instructions:
! WARNING
Halo SRL-LEs are tested and certified for horizontal use over a steel edge without burrs. Halo SRL-LEs may be
used over similar surfaces, such as metal sheeting or other steel formations.
The allowable angle of redirection of the lifeline portion of Halo SRL-LEs at the leading edge of a fall hazard
MUST be at least 90° (see Image 1).
Anchor point MUST be situated no lower than the leading edge of applicable fall hazard(s).
Prior to use, a Competent Person MUST calculate adequate fall clearance (see pg. 2).
ALWAYS attach to anchorage connector that will allow for required setback distance (see Image 2).
Setback distance: As determined by product testing, Guardian Fall Protection Halo SRL-LEs are not
required to be setback any specific distance from the leading edge of applicable fall hazard(s).
Halo SRL-LE may be used in combination with horizontal lifelines. All installation, set-up, and use of horizontal
lifelines must be done under the supervision of a Qualified Person.
NEVER work on the far side
of an opening that is
opposite the Halo SRL-LE
anchorage point.
In the event of a fall over
the edge, special rescue
measures may be necessary.
Always account for use of
Halo SRL-LE in job site rescue
plan developed by job site
Competent Person.
Do not remove shrink tube around shock absorber.
ALWAYS adhere to the following warnings and specifications when using SRL-LEs.
X≥90°
X≤90°
Image 1
Leading Edge
Setback Distance
Image 2
4
