DLP LightCrafter Single DLPC900 EVM Overview

5.2 DLP LightCrafter Single DLPC900 Evaluation Module (EVM) Hardware

The DLP LightCrafter Single DLPC900 EVM is one half of a complete DMD imaging electronics subsystem. The
DLP LightCrafter Single DLPC900 EVM consists of the single DLPC900 board which includes a single DLPC900
Digital Controller, a digital video receiver, flash memory, power management circuits, and supporting digital logic.
Also needed to complete the imaging subsystem is a DLP LightCrafter Single Controller DMD EVM which is
compatible with the LightCrafter Single DLPC900 EVM. A DMD EVM consists of a DMD, a DMD board (pcb)
containing on-board DMD power circuits, DMD mounting hardware when necessary, and a flexible (pcb) cable
for connections to the Single DLPC900 board.
Figure 5-1 outlines the major hardware components of a DLP LightCrafter Single DLPC900 System Hardware
Components.

Figure 5-1. DLP LightCrafter Single DLPC900 Hardware Components
