Shadowspec Unity Part Naming
When unpacking your Unity umbrella please check you have all the correct parts pictured below before beginning
assembly. If any parts are missing please contact support@shadowspec.com to resolve.
You will need to refer back to this page so why not earmark it for quick reference whilst you're assembling your umbrella.
Figure B - Unity Umbrella Parts
Top Cap
Top Pivot Block
Gas Spring
Through Spar
Carriage
Unity Mast
Rib Support (long/short)
Unity Spigot
Also included: Hex Key Set, No. 17 Ring Spanner
& a pot of grease for the spigot
Figure C - Frame Canopy Parts
Top Pivot Block
Spring Pivot
Shadowglide Button
Shadowglide
Handle
Upper Hub Assembly
Upper Rib (long/short)
Rotation Lock Lever
Main Spar
Gas Spring
Carriage
Lower Hub
with LED Light
Rib Tip with
Canopy Screws
Through Spar
S-Bend Pivot
Upper Rib
(Log / Short)
Rib Tip
with Canopy Screw
Top Cap
Top Pivot Block
Main Spar Gas Spring
Top Catch
Through Spar
Rotation Lock Lever
Security Lock Screw
Rotation Plate
Unity Spigot
Upper Hub Assembly
Rib Support Lower Hub with
(Log / Short) LED Light
Mast Channel
