Stage 1 - Key Dimensions of Your Shadowspec Unity

As the Shadowspec Unity is available to you in a variety of configurations, care must be taken to check the sizing of your
chosen umbrella in the following table.
Key Measurement Notes:
Free-Standing Base installations will add 165mm | 6'' to the height
Surface plates will add 12mm | 1/2'' to the height.
Adding Free-Standing Base wheels will add a further 45-80mm | 2-3'' to the height.
Figure A - Shadowspec Unity Umbrella Dimensions
C
B
A
F
G
Diagram Legend
A
Ground to central frame hub when closed*
B
Total height to top of canopy*
C
Height of umbrella to top of mast cap*
D
Ground to central frame hub when open*
E
Ground to lower outer edge of canopy*
F
Centre of Spigot to outside edge of canopy
G
Diagonal from centre of mast to corner
H
Duo/Quattro Umbrella Width Edge to Edge
I
Gutter Space Between Canopies
Note: All sizings and conversions are +/- 2.5mm / 2/32'' and are subject to change without notice.
It is recommended for commerical installations that metric measurements are used for any umbrella spacing to ensure accuracy
6
D
F
8' 2.5m
2'10'' 860mm
9'6'' 2900mm
9'6'' 2908mm
7'0'' 2130mm
7'3'' 2222mm
8'8'' 2646mm
12'3'' 3742mm
17'4'' 5292mm
6'' 160mm
H
I
10' 3.0m 11'
2'1'' 620mm 3'7''
9'3'' 2824mm 9'9''
9'6'' 2908mm 9'7''
6'9'' 2054mm 7'3''
7'3'' 2219mm 7'4''
9'10'' 2973mm 11'4''
13'10'' 4205mm N/A
19'6'' 5946mm 22'7''
6'' 160mm N/A
E
H
4.0m 13' 4.0m
866mm 2'10'' 866mm
2899mm 9'6'' 2899mm
2908mm 9'6'' 2908mm
2128mm 7'0'' 2128mm
2172mm 7'2'' 2172mm
3923mm 12'10'' 3923mm
N/A N/A N/A
6894mm 25'9'' 7846mm
N/A N/A N/A
