Stage 2 - Installation of Your Umbrella Mount

We offer four different mounting options. Please relate to the section relevant to your purchased mounting option.
We recommend that you read through all of the instructions before starting. It's worth it, trust us.
Step 1 First, unscrew the Security Lock Screw under the Rotating Lock Lever -
Step 2
Remove Spigot from your umbrella Mast.
Step 3 Affix the Spigot to your mounting option of choice (Options 1 - 4).
Step 4 Grease the Spigot with the supplied Spigot Grease.
Figure D - Location of Security Lock Screw
Security Lock Screw
Unity Spigot
1. Free-standing Base
Page 12
2. In-Ground Anchor
Page 14
Figure D.
Please don't use the
Rotation Lock Lever to
lift the Shadowspec Unity
Umbrella - it could break and
not be covered by warranty.
3. Surface Plate
Page 16
Unity Tools
Spigot Grease
4. Wall Base Bracket
Page 21
11
