Figure H - In-Ground Anchor Installation, Mast Orientation and Suggested Specifications
1.
Mast Orientation for Square Canopies
Unity Mast
2.
Mast Orientation for Octagon Canopies
Ground level
Flare Out
Canopy
Canopy
Canopy
Unity Spigot
500mm / 1'8'' ft
Canopy
Unity Spigot
Canopy
Canopy
Unity Mast
Unity Spigot
15
