Reinstalling the Enclosure

007-4644-003
To reinstall the enclosure into a rack, follow these steps:
1.
Install the support rails in the rack. See the procedure in the SGI InfiniteStorage
TP9300 and TP9300S RAID Installation and Upgrade Guide (108-0401-00x).
2. From the front of the rack, slide the enclosure into the rack along the support rails
(see Figure 3-5).
3. Fasten the rear and front mounting screws (see Figure 3-5).
4. Slide the top of the front bezel over the indicator lights and snap into place (see
Figure 3-4).
5. Wearing antistatic protection, reinstall the components into the enclosure. See
Chapter 4, "Replacing Enclosure Components" for more information.
Moving the Enclosure
45
