5: Cabling
82
5. To ensure power redundancy, plug each power distribution unit into a separate AC
power circuit (see Figure 5-11).
Controller enclosure
power supplies
Expansion enclosure
power supplies
Power
distribution
units (PDUs)
PDU Cabling
Figure 5-11
1Gb 1Gb 2Gb 2Gb
Conflict Conflict
X10 X10 X1 X1
Tray Number Tray Number
Breaker
switches
007-4644-003
