2: Storage Enclosures
Overview
14
Important: Several references are made in this chapter to the storage management
software (TPSSM). For complete information on the operation and use of this software,
see the SGI TPSSM Software Concepts Guide (007-4305-00x)
Figure 2-1 shows a front view of the storage enclosure. The front of the enclosure
contains the following components:
•
Front bezel: The bezel is a removable decorative cover with holes for viewing the
status LEDs and openings for the drive bays.
•
Disk drives: Up to 14 sled-mounted drives can be installed in the bays on the front
of the enclosure.
•
LEDs: There are two LEDs for each of the 14 drive bays that indicate the status of
the drive: the drive active LED and the drive fault LED. There are also two LEDs
that indicate the status of the entire enclosure: the enclosure fault LED and the
enclosure power LED.
•
Alarm mute button: This button silences the audible alarm of the controller
enclosure. The expansion enclosure does not have an alarm; therefore, the
expansion enclosure does not use this button.
Note: Controller enclosures and expansion controllers look identical when viewed from
the front.
.
007-4644-003
