Figure 4-10 Single-Controller Expansion Example - Silicon Graphics InfiniteStorage TP9300 User Manual

007-4644-003
Controller A
drive channel 1
Drive loop A
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
1Gb 2Gb
Conflict
X10 X1
Tray Number
Figure 4-10 Single-Controller Expansion Example
Controller
enclosure ID 00
Disk drive
enclosure ID 01
Disk drive
enclosure ID 02
Disk drive
enclosure ID 03
Disk drive
enclosure ID 04
Disk drive
enclosure ID 05
Disk drive
enclosure ID 06
Disk drive
enclosure ID 07
Adding Expansion Enclosures
67
