007-4644-003
Controller enclosure
power supplies
Expansion enclosure
power supplies
Power
distribution
units (PDUs)
Figure A-5 Power Connections to Controller and Expansion Enclosures
1Gb 1Gb 2Gb 2Gb
Conflict Conflict
X10 X10 X1 X1
Tray Number Tray Number
Breaker
switches
Rack Specifications
93
