A: Specifications and Requirements
Power Requirements
Power Distribution Units
92
Table A-2 lists the power requirements for the rack.
Table A-2 AC Power Requirements (Domestic and International)
Unit of Measure
AC distribution, 250 VAC, 16 A
Domestic, 250 VAC, 30 A
International, 230 VAC, 32 A
Voltage range
Frequency
Current specified at volt/freq
Circuit breaker
The rack has two PDUs (power distribution units). Each PDU has its own power cord.
Due to limited space inside the rack, it may be easier to connect and route power cords
before installing the support rails and enclosures.
To ensure redundancy, connect the PDUs in the rack to independent power circuits.
Connect one power cord from each enclosure to each PDU in the rack (see Figure A-5).
Requirement
Approved IEC 320-C19 connector
NEMA L6-30P locking plug, 6-30R receptacle (2)
IEC 309 locking plug; IEC 309 receptacle (2)
180 to 257 VAC
49 to 50.5 Hz or 59 to 60.6 Hz
220/50/60
25 A
007-4644-003
